30.323

30.323

30.323

Altech Corporation

30.323 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Altech Corporation stock available on our website

SOT-23

30.323 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 7 Weeks
Mounting Type Free Hanging (In-Line)
Package / Case 300
Housing Material Polyamide (PA66), Nylon 6/6
PackagingBulk
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Through Hole
Type Plug for Unshrouded Header
Number of Positions 3
Color Gray
Voltage - Rated 250V
Pitch 0.197 5.00mm
Insulation Height 0.425 10.80mm
Current Rating10A
Termination Style Screw
Approval Agency CSA, UL, VDE
Number of Levels 1
Wire Gauge (Max) 14 AWG
Wire Gauge (Min) 22 AWG
Voltage - UL 300V
Wire Gauge or Range - AWG 14-22 AWG
Plug Wire Entry 90°
Wire Gauge or Range - mm² 0.5-1.5mm2
Stripping Length 6mm
Height 10.8mm
Length 15mm
Width 13.5mm
RoHS StatusROHS3 Compliant
Lead Free Lead Free
In-Stock:3908 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$1.456763$1.456763
10$1.374305$13.74305
100$1.296514$129.6514
500$1.223127$611.5635
1000$1.153893$1153.893

30.323 Product Details

30.323 Overview


Free Hanging (In-Line) is the mount type.The product is packaged in a Bulk case.There is a device enclosed within the packaging with the 300.There are many benefits shared between this part and other Plug for Unshrouded Header products.

30.323 Features



30.323 Applications


There are a lot of Altech Corporation 30.323 Terminal Blocks applications.

  • Automotive Electronics
  • Industrial Automation
  • Refrigeration control
  • Communication
  • Anywhere power is distributed
  • Instrumentation
  • Control panels
  • LED municipal outdoor and street lighting
  • Blowers
  • All Electrical Machinery
