Name: AD743KN
Brand: Analog Devices, Inc.
SKU: AD743KN
Availability: InStock

new-10%

AD743KN

Manufacturer part number:AD743KN

Manufacturer:Analog Devices, Inc.

Description:102 dB Instrumentational OP Amps 0.0004μA 8 Pins PDIP

Case Package:SOT-23

Datasheet:AD743KN Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Package / Case	PDIP
Surface Mount	NO
JESD-609 Code	e0
Number of Terminations	8
ECCN Code	EAR99
Terminal Finish	Tin/Lead (Sn/Pb)
Subcategory	Operational Amplifier
Technology	BIPOLAR
Terminal Position	DUAL
Terminal Form	THROUGH-HOLE
Peak Reflow Temperature (Cel)	240
Number of Functions	1
Supply Voltage	15V
Terminal Pitch	2.54mm
Reach Compliance Code	not_compliant
Time@Peak Reflow Temperature-Max (s)	30
Pin Count	8
Qualification Status	Not Qualified
Operating Temperature (Max)	70°C
Temperature Grade	COMMERCIAL
Number of Circuits	1
Slew Rate	2.8 V/us
Architecture	VOLTAGE-FEEDBACK
Amplifier Type	OPERATIONAL AMPLIFIER
Common Mode Rejection Ratio	102 dB
Neg Supply Voltage-Nom (Vsup)	-15V
Unity Gain BW-Nom	4500 kHz
Average Bias Current-Max (IIB)	0.0004μA
Low-Offset	NO
Frequency Compensation	YES
Low-Bias	YES
Bias Current-Max (IIB) @25C	0.00025μA
Input Offset Current-Max (IIO)	0.0032μA
Common-mode Reject Ratio-Min	88 dB
Height Seated (Max)	4.44mm
Width	7.62mm
RoHS Status	Non-RoHS Compliant

AD743KN Product Details

AD743KN Overview

The linear amplifier is packaged in a PDIP case. This is a OPERATIONAL AMPLIFIER type op amp. The number of terminations approaches 8. Buffer amplifier has a total of 8 pins. Please take in mind that this instrumentation amplifier should be run at 15V. To be specific, this instrumentation amplifier is a type of Operational Amplifier. There are 1 circuits on this op amp.
