Name: 12146AGX408
Brand: APEM Inc.
SKU: 12146AGX408
Price: 66.42000 USD
Availability: InStock

new

12146AGX408

Manufacturer part number:12146AGX408

Manufacturer:APEM Inc.

Description:SWITCH TOGGLE DPDT 4A 125V

Case Package:SOT-23

Datasheet:12146AGX408 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	9 Weeks
Contact Material	Silver
Mount	Panel
Mounting Type	Panel Mount
Housing Material	Brass
Actuator Material	Brass, Chrome Plated
Operating Temperature	-40°C~85°C
Packaging	Bulk
Series	12000
Feature	Front Panel Sealing
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
Voltage - Rated DC	30V
Current Rating (Amps)	4A AC/DC
Orientation	Straight
Current Rating	4A
Termination Style	Solder Lug
Voltage - Rated AC	125V
Actuator Type	Standard Round
Circuit	DPDT
Switch Function	On-On
Panel Cutout Dimensions	Circular - 12.00mm Dia
Contact Resistance	10mOhm
Insulation Resistance	1000000000Ohm
Contact Current(DC)-Max	4A
Sealing	EPOXY
Max Voltage Rating (AC)	250V
Dielectric Withstanding Voltage	2000VRMS V
Electrical Life	50,000 Cycles
Illumination	Non-Illuminated
Max Voltage Rating (DC)	30V
Mechanical Life	150000 cycles
Switch Type	TOGGLE SWITCH
Contact Current Rating	4A
Bushing Thread	15/32-32
Contact Current(AC)-Max	4A
Contact (AC) Max Rating R Load	4A@125VAC
Contact (DC) Max Rating R Load	4A@30VDC
Bushing Length	0.429 inch
Actuator Finish	MATTE
Body Height	13.6906mm
Length - Termination	0.196 inch
Actuator Length	17.30mm
REACH SVHC	No SVHC
RoHS Status	ROHS3 Compliant

12146AGX408 Product Details

The APEM 12146AGX408 Toggle Switch is a double pole double throw (DPDT) switch designed for use in a variety of applications. It has a 4A current rating and a 125V voltage rating. It is a two-position switch with a center off position. It is a panel mount switch with a threaded bushing and a solder lug terminal. It is a momentary switch with a black plastic actuator and a black plastic body.

Features of the APEM 12146AGX408 Toggle Switch include a long life of up to 10,000 cycles, a high contact rating, and a low contact resistance. It is also UL and CSA approved.

Applications of the APEM 12146AGX408 Toggle Switch include industrial control, automotive, and consumer electronics. It is suitable for use in a variety of applications such as lighting control, motor control, and power switching.
