Name: 5238AB
Brand: APEM Inc.
SKU: 5238AB
Price: 7.56000 USD
Availability: InStock

new-10%

5238AB

Manufacturer part number:5238AB

Manufacturer:APEM Inc.

Description:SWITCH TOGGLE SPDT 6A 125V

Case Package:SOT-23

Datasheet:5238AB Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	5 Weeks
Mount	Panel
Mounting Type	Panel Mount
Actuator Material	Brass, Nickel Plated
Operating Temperature	-40°C~85°C
Packaging	Tray
Series	5000
JESD-609 Code	e4
Feature	Epoxy Sealed Terminals
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	PC Pin
ECCN Code	EAR99
Terminal Finish	Silver (Ag)
HTS Code	8536.50.90.65
Voltage - Rated DC	30V
Current Rating (Amps)	6A AC 4A DC
Current Rating	4A
Termination Style	PC Pin
Voltage - Rated AC	125V
Body Length or Diameter	13.2mm
Body Breadth	7 mm
Actuator Type	Standard Round
Circuit	SPDT
Switch Function	On-Off-Mom
Panel Cutout Dimensions	Circular - 6.50mm Dia
Contact Current(DC)-Max	4A
Sealing	EPOXY TERMINAL SEALED
Electrical Life	50,000 Cycles
Illumination	Non-Illuminated
Switch Type	TOGGLE SWITCH
Bushing Thread	1/4-40
Contact Current(AC)-Max	6A
Contact (AC) Max Rating R Load	6A@125VAC
Body Height	13.3mm
Actuator Length	10.50mm
RoHS Status	ROHS3 Compliant

5238AB Product Details

Description:
APEM 5238AB Toggle Switches are single-pole double-throw (SPDT) switches designed for use in a variety of applications. The switches feature a 6A 125V rating and are available in a variety of actuator styles.

Features:
- 6A 125V rating
- SPDT configuration
- Variety of actuator styles
- High-quality construction
- RoHS compliant

Applications:
APEM 5238AB Toggle Switches are suitable for a variety of applications, including industrial control, automotive, and consumer electronics. The switches are suitable for use in applications requiring a high-quality, reliable switch.
