Name: 5656AB
Brand: APEM Inc.
SKU: 5656AB
Price: 28.27000 USD
Availability: InStock

new

5656AB

Manufacturer part number:5656AB

Manufacturer:APEM Inc.

Description:SWITCH TOGGLE 3PDT 6A 125V

Case Package:SOT-23

Datasheet:5656AB Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	5 Weeks
Contact Material	Silver
Mount	Panel
Mounting Type	Panel Mount
Housing Material	Stainless Steel
Actuator Material	Brass, Nickel Plated
Operating Temperature	-40°C~85°C
Packaging	Tray
Series	5000
JESD-609 Code	e4
Feature	Epoxy Sealed Terminals
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
HTS Code	8536.50.90.65
Voltage - Rated DC	30V
Current Rating (Amps)	6A AC 4A DC
Orientation	Straight
Current Rating	4A
Termination Style	Solder Lug
Voltage - Rated AC	125V
Body Length or Diameter	16.5mm
Body Breadth	13.2 mm
Actuator Type	Standard Round
Circuit	3PDT
Switch Function	On-On
Panel Cutout Dimensions	Circular - 6.50mm Dia
Contact Resistance	10mOhm
Insulation Resistance	1000000000Ohm
Contact Current(DC)-Max	4A
Sealing	EPOXY TERMINAL SEALED
Max Voltage Rating (AC)	250V
Dielectric Withstanding Voltage	1500VRMS V
Electrical Life	40,000 Cycles
Illumination	Non-Illuminated
Max Voltage Rating (DC)	30V
Mechanical Life	100000 cycles
Switch Type	TOGGLE SWITCH
Illumination Type	Illuminated, Non-Illuminated
Bushing Thread	1/4-40
Contact Current(AC)-Max	6A
Contact (AC) Max Rating R Load	[email protected]
Contact (DC) Max Rating R Load	[email protected]
Bushing Length	0.314 inch
Actuator Finish	CHROME
Body Height	13.1mm
Length - Termination	0.145 inch
Actuator Length	10.50mm
RoHS Status	ROHS3 Compliant

5656AB Product Details

Description:

The APEM 5656AB Toggle Switch is a 3-pole double-throw (3PDT) switch with a 6A 125V rating. It is designed for use in a variety of applications, including industrial, commercial, and residential. The switch features a black plastic body and a black plastic actuator.

Features:
• 3-pole double-throw (3PDT) switch
• 6A 125V rating
• Black plastic body and actuator
• UL, CSA, and VDE approved
• RoHS compliant
• IP67 rated
• Momentary and latching options available

Applications:
The APEM 5656AB Toggle Switch is suitable for a variety of applications, including industrial, commercial, and residential. It can be used for controlling motors, lights, and other electrical devices. It is also suitable for use in harsh environments, as it is IP67 rated.
