637H/2 datasheet pdf and Toggle Switches product details from APEM Inc. stock available on our website
SOT-23
637H/2 Datasheet PDF
non-compliant
Technical Specifications
Parameter Name
Value
Type
Parameter
Factory Lead Time
6 Weeks
Contact Material
Silver
Mount
Panel
Mounting Type
Panel Mount
Package / Case
Metal
Number of Pins
1
Housing Material
Polyester
Actuator Material
Brass, Nickel Plated
Operating Temperature
-20°C~55°C
Packaging
Bulk
Series
600H
Part Status
Active
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Termination
Solder
Number of Positions
3
Voltage - Rated DC
24V
Current Rating (Amps)
10A AC
Orientation
Straight
Current Rating
10A
Termination Style
Quick Connect - 0.250 (6.3mm)
Voltage - Rated AC
125V
Actuator Type
Standard Round
Circuit
SPDT
Switch Function
Mom-Off-Mom
Panel Cutout Dimensions
Circular - 12.20mm Dia
Contact Resistance
10mOhm
Insulation Resistance
1GOhm
Max Voltage Rating (AC)
400V
Max Current Rating
15A
Electrical Life
10,000 Cycles
Illumination
Non-Illuminated
Max Voltage Rating (DC)
25V
Contact Current Rating
5A
Illumination Type
Illuminated, Non-Illuminated
Bushing Thread
M12 x 0.75
Switching Current
10A
Length
29.5mm
Actuator Length
17.50mm
REACH SVHC
No SVHC
RoHS Status
ROHS3 Compliant
Lead Free
Lead Free
In-Stock:886 items
Pricing & Ordering
Quantity
Unit Price
Ext. Price
1
$10.567439
$10.567439
10
$9.969282
$99.69282
100
$9.404983
$940.4983
500
$8.872626
$4436.313
1000
$8.370401
$8370.401
637H/2 Product Details
The APEM Toggle Switches 637H/2 are a reliable and durable switch solution for a variety of applications. This single pole double throw (SPDT) switch is rated for 10A at 125V and is designed to provide reliable switching performance in a variety of environments. The switch features a rugged construction with a black plastic body and a silver-plated brass contact. The switch is also designed to be easy to install and use, with a simple toggle action and a large, easy-to-grip handle. The switch is also UL and CSA approved, making it suitable for use in a variety of applications. With its reliable performance and durable construction, the APEM Toggle Switches 637H/2 is an ideal choice for a variety of applications.
