Name: TL39WS84000
Brand: APEM Inc.
SKU: TL39WS84000
Price: 7.61000 USD
Availability: InStock

new-10%

TL39WS84000

Manufacturer part number:TL39WS84000

Manufacturer:APEM Inc.

Description:Switch Toggle ON OFF ON SPDT Round Lever Gull Wing 20VAC 20VDC 0.4VA PC Mount with Bracket T/R

Case Package:SOT-23

Datasheet:TL39WS84000 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	9 Weeks
Contact Material	Brass
Contact Plating	Gold
Mount	Surface Mount
Mounting Type	Surface Mount, Right Angle
Housing Material	THERMOPLASTIC
Actuator Material	Brass, Nickel Plated
Operating Temperature	-40°C~85°C
Packaging	Bulk
Series	SMT TL
JESD-609 Code	e3
Feature	High Temperature Plastic Cap
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Gull Wing
ECCN Code	EAR99
Terminal Finish	Tin (Sn)
Additional Feature	TAPE & REEL PACKAGING
HTS Code	8536.50.90.65
Voltage - Rated DC	20V
Current Rating (Amps)	0.4VA AC/DC
Packing Method	TAPE AND REEL
Termination Style	Gull Wing
Voltage - Rated AC	20V
Actuator Type	Standard Round
Circuit	SPDT
Switch Function	On-Off-On
Contact Resistance	0.02mOhm
Insulation Resistance	1000000000Ohm
Contact Current(DC)-Max	0.02A
Sealing	EPOXY
Max Voltage Rating (AC)	20V
Dielectric Withstanding Voltage	1000VRMS V
Electrical Life	30,000 Cycles
Illumination	Non-Illuminated
Max Voltage Rating (DC)	20V
Switch Type	TOGGLE SWITCH
Bushing Thread	Unthreaded
Contact Current(AC)-Max	0.02A
Contact (AC) Max Rating R Load	[email protected]
Contact (DC) Max Rating R Load	[email protected]
Solderability	WAVE
Contact (AC) Max Power Rating R Load	[email protected]
Washability	WATER/STEAM
Length	8.1mm
Body Height	5.55mm
Actuator Length	5.50mm
RoHS Status	ROHS3 Compliant

About TL39WS84000

The TL39WS84000 from APEM Inc. is a high-performance microcontroller designed for a wide range of embedded applications. This component features Switch Toggle ON OFF ON SPDT Round Lever Gull Wing 20VAC 20VDC 0.4VA PC Mount with Bracket T/R.

Key Features

Advanced AVR architecture for efficient processing
Wide operating temperature range: -40°C to 85°C
Low power consumption for energy-efficient applications
Comprehensive peripheral set including SPI, UART, and USART interfaces

Applications

This microcontroller is ideal for various applications including:

Industrial control systems
Consumer electronics
Automotive systems
IoT devices
Medical equipment

Technical Support

Hotenda provides comprehensive technical support for the TL39WS84000, including datasheets, application notes, and design resources. Our team of engineers is available to assist with your design challenges.
