ASMT-UBB5-NS8Q2 datasheet pdf and LED Indication - Discrete product details from Broadcom Limited stock available on our website
SOT-23
ASMT-UBB5-NS8Q2 Datasheet PDF
non-compliant
Technical Specifications
Parameter Name
Value
Type
Parameter
Factory Lead Time
13 Weeks
Contact Plating
Tin
Mount
Surface Mount
Mounting Type
Surface Mount
Package / Case
2-PLCC
Number of Pins
2
Shape
RECTANGULAR
Packaging
Tape & Reel (TR)
Published
2010
Size / Dimension
3.20mm Lx2.80mm W
JESD-609 Code
e3
Part Status
Active
Moisture Sensitivity Level (MSL)
2A (4 Weeks)
Number of Terminations
2
Max Operating Temperature
100°C
Min Operating Temperature
-40°C
Color
Blue
Additional Feature
HIGH RELIABILITY
Subcategory
Visible LEDs
Power Rating
114mW
Packing Method
TAPE AND REEL 7"
Max Power Dissipation
114mW
Number of Functions
1
Terminal Pitch
3mm
Depth
3.2mm
Base Part Number
ASMT-U*B5
Number of Elements
1
Configuration
Standard
Power Dissipation
114W
Voltage - Forward (Vf) (Typ)
3.2V
Viewing Angle
120°
Optoelectronic Device Type
SINGLE COLOR LED
Forward Current
20mA
Lens Style
Round with Flat Top
Lens Size
2.20mm Dia
Luminous Intensity
392 mcd
Millicandela Rating
392mcd
Lens Transparency
Clear
Lens Color
Colorless
Reverse Voltage
5V
Wavelength
470 nm
Height
2.1mm
REACH SVHC
No SVHC
Radiation Hardening
No
RoHS Status
ROHS3 Compliant
In-Stock:8821 items
Pricing & Ordering
Quantity
Unit Price
Ext. Price
1
$0.701002
$0.701002
10
$0.661323
$6.61323
100
$0.623889
$62.3889
500
$0.588575
$294.2875
1000
$0.555259
$555.259
ASMT-UBB5-NS8Q2 Product Details
Description: The Broadcom ASMT-UBB5-NS8Q2 is a surface mount LED indicator designed for use in a variety of applications. It is a PLCC2 package with silicone encapsulation and a blue color. The LED has a forward voltage of 2.2V and a forward current of 20mA.
Features: - PLCC2 package with silicone encapsulation - Blue color - Forward voltage of 2.2V - Forward current of 20mA
Applications: The Broadcom ASMT-UBB5-NS8Q2 LED indicator is suitable for use in a variety of applications, including automotive, industrial, and consumer electronics. It can be used as a status indicator, warning light, or decorative lighting.
