HSMZ-C190 Datasheet PDF
non-compliant
Technical Specifications
Parameter Name
Value
Type
Parameter
Factory Lead Time
13 Weeks
Mount
Surface Mount
Mounting Type
Surface Mount
Package / Case
0603 (1608 Metric)
Number of Pins
2
Shape
RECTANGULAR
Packaging
Tape & Reel (TR)
Published
2008
Size / Dimension
1.60mm Lx0.80mm W
JESD-609 Code
e4
Part Status
Active
Moisture Sensitivity Level (MSL)
2A (4 Weeks)
Number of Terminations
2
ECCN Code
EAR99
Terminal Finish
Gold (Au) - with Nickel (Ni) barrier
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Color
Red
Subcategory
Visible LEDs
Power Rating
60mW
Packing Method
TAPE AND REEL 7"
Number of Functions
1
Depth
800μm
Base Part Number
HSMZ-C190
Case Code (Metric)
1608
Case Code (Imperial)
0603
Number of Elements
1
Configuration
Standard
Power Dissipation
65mW
Voltage - Forward (Vf) (Typ)
2.2V
Viewing Angle
170°
Optoelectronic Device Type
SINGLE COLOR LED
Forward Current
20mA
Lens Style
Rectangle with Flat Top
Lens Size
1.00mmx0.80mm
Luminous Intensity
165 mcd
Lens Transparency
Diffused
Wavelength - Peak
643nm
Lens Color
White
Luminous Flux
122 lm
Reverse Voltage
5V
Wavelength - Dominant
631nm
Height
800μm
REACH SVHC
No SVHC
Radiation Hardening
No
RoHS Status
ROHS3 Compliant
Lead Free
Lead Free
In-Stock:12469 items
Pricing & Ordering
Quantity
Unit Price
Ext. Price
1
$0.596198
$0.596198
10
$0.562451
$5.62451
100
$0.530614
$53.0614
500
$0.500579
$250.2895
1000
$0.472244
$472.244
HSMZ-C190 Product Details
Description:
The Broadcom LED Indication - Discrete HSMZ-C190 is a uni-color red 643nm 2-pin chip LED in a through-hole package. It is designed for use in a variety of applications, including automotive, industrial, and consumer electronics. The LED has a wide viewing angle and is RoHS compliant.
Features:
• Uni-color red 643nm LED • 2-pin chip LED in a through-hole package • Wide viewing angle • RoHS compliant • Low power consumption • High reliability
Applications:
The Broadcom LED Indication - Discrete HSMZ-C190 is suitable for use in a variety of applications, including automotive, industrial, and consumer electronics. It can be used for backlighting, indicator lights, and status displays. It is also suitable for use in medical and military applications.
