Name: 0026482052
Brand: Molex
SKU: 0026482052
Price: 1.52000 USD
Availability: InStock

new-10%

0026482052

Manufacturer part number:0026482052

Manufacturer:Molex

Description:0026482052 datasheet pdf and Rectangular Connectors - Headers, Male Pins product details from Molex stock available on our website

Case Package:SOT-23

Datasheet:0026482052 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Contact Material	Brass
Mounting Type	Through Hole, Right Angle
Contact Shape	Square
Insulation Material	Polyester, Glass Filled
Packaging	Bulk
Series	KK 41662
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Header, Breakaway
Number of Positions	5
Applications	Automotive, General Purpose, Industrial, Medical, Telecommunications
Number of Rows	1
Additional Feature	POLARIZED
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Male Pin
Mixed Contacts	NO
Terminal Pitch	3.96mm
Insulation Height	0.128 3.25mm
Style	Board to Board or Cable
Number of Positions Loaded	All
Pitch - Mating	0.156 3.96mm
Insulation Color	Black
Contact Length - Post	0.184 4.67mm
Shrouding	Unshrouded
Contact Finish - Post	Tin
Contact Length - Mating	0.573 14.55mm
UL Flammability Code	94V-0
Contact Finish Thickness - Mating	20.0μin 0.51μm
Contact Finish Thickness - Post	100.0μin 2.54μm
Material Flammability Rating	UL94 V-0
RoHS Status	ROHS3 Compliant

0026482052 Product Details

0026482052 Overview

It comes in a Header, Breakaway package.Through Hole, Right Angle is the type of mounting for the device.The product is packaged in a Bulk case.Among the products in the KK 41662 Series, it is one of the most popular.Further, there are features such as POLARIZED, to name only a few.There's an application for the device called Automotive, General Purpose, Industrial, Medical, Telecommunications.
