Name: 0395005003
Brand: Molex
SKU: 0395005003
Price: 1.55000 USD
Availability: InStock

new-10%

0395005003

Manufacturer part number:0395005003

Manufacturer:Molex

Description:0395005003 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Molex stock available on our website

Case Package:SOT-23

Datasheet:0395005003 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Contact Material	Phosphor Bronze
Contact Plating	Tin
Mount	Cable, Free Hanging
Mounting Type	Free Hanging (In-Line)
Housing Material	Polyamide (PA66), Nylon 6/6
Operating Temperature	-40°C~115°C
Packaging	Bulk
Series	Eurostyle ESE 39500
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Screw
Type	Plug, Female Sockets
Number of Positions	3
Max Operating Temperature	115°C
Min Operating Temperature	-40°C
Color	Green
Number of Rows	1
Pitch	0.138 3.50mm
Orientation	Right Angle
Insulation Height	0.440 11.18mm
Termination Style	Screw - Rising Cage Clamp
Number of Contacts	3
Housing Color	Green
Voltage	300V
Number of Levels	1
Current	8A
Wire Gauge (Max)	30 AWG
Wire Gauge (Min)	16 AWG
Contact Mating Finish	Tin
Voltage - UL	300V
Wire Gauge or Range - AWG	16-30 AWG
Current - UL	8A
Torque - Screw	0.23 Nm (2.0 Lb-In)
Positions Per Level	3
Plug Wire Entry	180°
Wire Strip Length	6.5mm
Number of Positions Per Level	3
Material Flammability Rating	UL94 V-0
RoHS Status	ROHS3 Compliant

0395005003 Product Details

0395005003 Overview

The mounting type of the device is Free Hanging (In-Line).A Bulk case is used to package the product.Among the products in the Eurostyle ESE 39500 Series, it is one of the most popular.A temperature below 115°C is best for using it.A minimum operating temperature of -40°C is required for this device.You've got Cable, Free Hanging mounted on the part.Running in -40°C~115°C Operating Temperature.It shares many benefts with other Plug, Female Sockets products.
