Name: 0878326222
Brand: Molex
SKU: 0878326222
Price: 5.30000 USD
Availability: InStock

new-10%

0878326222

Manufacturer part number:0878326222

Manufacturer:Molex

Description:0878326222 datasheet pdf and Rectangular Connectors - Headers, Male Pins product details from Molex stock available on our website

Case Package:SOT-23

Datasheet:0878326222 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	11 Weeks
Contact Material	Phosphor Bronze
Contact Plating	Gold
Mount	Surface Mount
Mounting Type	Surface Mount
Contact Shape	Square
Insulation Material	Polyamide (PA), Nylon, Glass Filled
Housing Material	Nylon
Packaging	Tape & Reel (TR)
Series	Milli-Grid 87832
Feature	Board Guide, Keying Slot, Pick and Place
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Header
Number of Positions	26
Max Operating Temperature	105°C
Min Operating Temperature	-55°C
Color	Black
Applications	Automotive, General Purpose, Telecommunications
Number of Rows	2
Fastening Type	Latch Holder
Contact Finish - Mating	Gold
Contact Type	Male Pin
Pitch	2mm
Orientation	Vertical
Depth	6.3mm
Insulation Height	0.252 6.40mm
Style	Board to Board or Cable
Number of Positions Loaded	All
Current Rating	2A
Pitch - Mating	0.079 2.00mm
Insulation Color	Black
Row Spacing - Mating	0.079 (2.00mm)
Shrouding	Shrouded - 4 Wall
Number of Contacts	26
Contact Finish - Post	Tin
Contact Length - Mating	0.141 3.60mm
Housing Color	Black
Number of Circuits	24
Length	28.65mm
Contact Finish Thickness - Mating	15.0μin 0.38μm
Contact Finish Thickness - Post	74.8μin 1.90μm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

0878326222 Product Details

0878326222 Overview

This product is packaged in a Header carton.This device's mounting type is Surface Mount.A Tape & Reel (TR) case is used to package the product.The product belongs to the Milli-Grid 87832 Series.Using it at a temperature below 105°C is ideal.-55°C is the minimum temperature this device can operate at.This device can be used for Automotive, General Purpose, Telecommunications.With its Board Guide, Keying Slot, Pick and Place feature, it is more powerful in many ways.There is a mounting hole at Surface Mount.Part 24 consists of circuits of 0 ohms.
