5972901602F

new-10%

Manufacturer part number:5972901602F

Manufacturer:Dialight

Description:LED BLUE CLEAR 1208 SMD R/A

Case Package:SOT-23

Datasheet:5972901602F Datasheet

RoHs Status:non-compliant

Name	Value
Type	Parameter
Factory Lead Time	10 Weeks
Mounting Type	Surface Mount, Right Angle
Package / Case	2-SMD, No Lead
Surface Mount	YES
Shape	RECTANGULAR
Packaging	Strip
Published	2009
Series	597
Size / Dimension	3.00mm Lx2.00mm W
JESD-609 Code	e4
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	3
Terminal Finish	Gold (Au) - with Nickel (Ni) barrier
Color	Blue
HTS Code	8541.40.20.00
Number of Functions	1
Operating Temperature (Max)	85°C
Operating Temperature (Min)	-55°C
Configuration	Standard
Voltage - Forward (Vf) (Typ)	3.3V
Viewing Angle	130°
Optoelectronic Device Type	SINGLE COLOR LED
Current - Test	20mA
Lens Style	Rectangle with Domed Top
Lens Size	2.00mmx1.00mm
Luminous Intensity	125.0 mcd
Millicandela Rating	125mcd
Lens Transparency	Clear
Wavelength - Peak	468nm
Lens Color	Colorless
Forward Current-Max	0.02A
Overall Height	1mm
Wavelength - Dominant	470nm
Height (Max)	1.00mm
RoHS Status	ROHS3 Compliant
