Name: MBR730
Brand: Diodes Incorporated
SKU: MBR730
Availability: InStock

new-10%

MBR730

Manufacturer part number:MBR730

Manufacturer:Diodes Incorporated

Description:MBR730 datasheet pdf and Diodes - Rectifiers - Single product details from Diodes Incorporated stock available on our website

Case Package:SOT-23

Datasheet:MBR730 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Through Hole
Mounting Type	Through Hole
Package / Case	TO-220-2
Number of Pins	2
Weight	6.000006g
Diode Element Material	SILICON
Packaging	Tube
Published	2005
JESD-609 Code	e3
Pbfree Code	no
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
ECCN Code	EAR99
Terminal Finish	Matte Tin (Sn)
Max Operating Temperature	150°C
Min Operating Temperature	-55°C
Additional Feature	LOW POWER LOSS, FREE WHEELING DIODE
Subcategory	Rectifier Diodes
Peak Reflow Temperature (Cel)	260
[email protected] Reflow Temperature-Max (s)	40
Pin Count	3
Number of Elements	1
Element Configuration	Single
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Diode Type	Schottky
Current - Reverse Leakage @ Vr	100μA @ 30V
Voltage - Forward (Vf) (Max) @ If	840mV @ 15A
Case Connection	CATHODE
Forward Current	7.5A
Operating Temperature - Junction	-55°C~150°C
Application	EFFICIENCY
Forward Voltage	840mV
Max Reverse Voltage (DC)	30V
Average Rectified Current	7.5A
Number of Phases	1
Peak Reverse Current	100μA
Max Repetitive Reverse Voltage (Vrrm)	30V
Capacitance @ Vr, F	400pF @ 4V 1MHz
Peak Non-Repetitive Surge Current	150A
Max Forward Surge Current (Ifsm)	150A
Height	8.89mm
Length	10.4mm
Width	4.82mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

MBR730 Product Details

MBR730 Overview

A rectified current of 7.5A volts is averaged for this device.When the forward current reaches 7.5A, it is allowed.The datasheets show a peak reverse of 100μA, as shown in the data chart.
