Name: FXE167F96F66LACXP
Brand: Infineon Technologies
SKU: FXE167F96F66LACXP
Availability: InStock

new-10%

FXE167F96F66LACXP

Manufacturer part number:FXE167F96F66LACXP

Manufacturer:Infineon Technologies

Description:Microcontroller 144 Pin LQFP

Case Package:SOT-23

Datasheet:FXE167F96F66LACXP Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Package / Case	LQFP
Surface Mount	YES
Number of Pins	144
Number of Terminations	144
Technology	CMOS
Terminal Position	QUAD
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Terminal Pitch	0.5mm
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Operating Temperature (Max)	85°C
Operating Temperature (Min)	-40°C
Supply Voltage-Max (Vsup)	1.6V
Temperature Grade	INDUSTRIAL
Supply Voltage-Min (Vsup)	1.4V
Number of I/O	115
Speed	66 MHz
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Clock Frequency	66MHz
Bit Size	16
Has ADC	YES
DMA Channels	YES
PWM Channels	YES
DAC Channels	NO
Address Bus Width	24
ROM (words)	786432
On Chip Program ROM Width	8
External Data Bus Width	16
RAM (bytes)	65536
ROM Programmability	FLASH
Length	20mm
Height Seated (Max)	1.6mm
Width	20mm
RoHS Status	RoHS Compliant

FXE167F96F66LACXP Product Details

FXE167F96F66LACXP Overview

Packaged in a LQFP format, this MCU is available in a compact size. There are 115 I/Os on the Microcontroller. This is a MICROCONTROLLER, RISC uPs/uCs/Peripheral IC. During the manufacturing process, 144 terminations were applied to the IC chip. 16-bits are used in Microcontroller. Currently, MCU chip has YES DMA channels. There are YES PWM channels on the device. The chip has 144 pins. The clock function of this device is based on a 66MHz-frequency.
