Name: ICE3DS01LG
Brand: Infineon Technologies
SKU: ICE3DS01LG
Availability: InStock

new-10%

ICE3DS01LG

Manufacturer part number:ICE3DS01LG

Manufacturer:Infineon Technologies

Description:8 Terminations8.5V~20V ICE3DS01 AC to DC power converterCoolSET?F3 Series 110kHz

Case Package:SOT-23

Datasheet:ICE3DS01LG Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Surface Mount
Package / Case	8-SOIC (0.154, 3.90mm Width)
Surface Mount	YES
Operating Temperature	-25°C~130°C TJ
Packaging	Tape & Reel (TR)
Published	2005
Series	CoolSET®F3
JESD-609 Code	e3
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	8
ECCN Code	EAR99
Terminal Finish	MATTE TIN
HTS Code	8542.39.00.01
Subcategory	Switching Regulator or Controllers
Max Power Dissipation	450mW
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Number of Functions	1
Terminal Pitch	1.27mm
Base Part Number	ICE3DS01
Pin Count	8
JESD-30 Code	R-PDSO-G8
Input Voltage-Nom	15V
Analog IC - Other Type	SWITCHING CONTROLLER
Voltage - Supply (Vcc/Vdd)	8.5V~20V
Control Features	Soft Start
Input Voltage (Min)	9V
Topology	Flyback
Control Mode	CURRENT-MODE
Output Current-Max	0.7A
Frequency - Switching	110kHz
Input Voltage (Max)	20V
Control Technique	PULSE WIDTH MODULATION
Breakdown Voltage	500V
Switcher Configuration	SINGLE
Internal Switch(s)	No
Fault Protection	Current Limiting, Open Loop, Over Load, Over Temperature, Over Voltage
Duty Cycle	72%
Output Isolation	Isolated
Voltage - Start Up	15V
Height Seated (Max)	1.73mm
Length	5mm
Width	4mm
RoHS Status	RoHS Compliant
Lead Free	Lead Free

ICE3DS01LG Product Details

ICE3DS01LG Overview

The ac to dc converter is embedded in 8-SOIC (0.154, 3.90mm Width) package.It is available in Tape & Reel (TR) AC/DC power converter.A AC/DC converter of this type is mounted in the way of Surface Mount .For the ac dc converter to perform properly, it should be operated at a temperature of -25°C~130°C TJ °C.An analog IC of type SWITCHING CONTROLLER is employed in this AC DC converter.As soon as the switching frequency reaches 110kHz , the circuit is closed.As long as the supply voltage (Vcc/Vdd) is within the range of 8.5V~20V , the AC/DC converter may be used.There are a total of 8 terminations.Up to 8 pins are present on the ac-dc converter.It belongs to the family of CoolSET?F3 manufacturers.The ICE3DS01 family allows you to search for similar acdc converters.Switching Regulator or Controllers contains the ac to dc conversions.Using a unique technique, a voltage with a maximum value of 20V can be ensured.Ac to dc inverters can be powered by up to 0.7A current.
