LT1014DSW Overview
In the package, you will find a 16-SOIC (0.295, 7.50mm Width)-case to contain the op amp ic. The instrumentation amplifier in this picture is of the General Purpose-type. A Tube case is used for delivering the op amp. During the past two weeks, there have been close to 16 terminations. A total of 16 pins are located on this board. This linear amplifier should be powered by an 15V battery. This particular linear amplifier is a type of Operational Amplifier device, to be precise. For this electrical component, Surface Mount is the recommended mounting type. According to the manufacturer, this buffer op amp works well at 0°C~70°C , which is a good operating temperature. A instrumentation amplifier like this has 4 circuits. There is a recommendation that this electrical part be used with a supply with 350μA current rating. In this op amp ic, the minimum voltage gain is 700000.
LT1014DSW Features
16 Pins
supply voltage of 15V
LT1014DSW Applications
There are a lot of Linear Technology/Analog Devices
LT1014DSW Instrumentational OP Amps applications.
- Multiplication circuits
- Division circuits
- Precision measurement
- Power control
- Information processing
- Weak signal detection
- Signal amplification
- Signal filtering
- Signal operation
- Video computer boards
