Name: LTST-S270KRKT
Brand: Lite-On Inc.
SKU: LTST-S270KRKT
Price: 0.24000 USD
Availability: InStock

new-10%

LTST-S270KRKT

Manufacturer part number:LTST-S270KRKT

Manufacturer:Lite-On Inc.

Description:LTST-S270KRKT datasheet pdf and LED Indication - Discrete product details from Lite-On Inc. stock available on our website

Case Package:SOT-23

Datasheet:LTST-S270KRKT Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount, Right Angle
Package / Case	0603 (1608 Metric)
Number of Pins	2
Shape	RECTANGULAR
Packaging	Cut Tape (CT)
Published	2001
Size / Dimension	1.60mm Lx1.15mm W
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	2
ECCN Code	EAR99
Max Operating Temperature	85°C
Min Operating Temperature	-30°C
Color	Red
Additional Feature	IC COMPATIBLE, SIDE VIEW
Subcategory	Visible LEDs
Power Rating	75mW
Packing Method	TAPE AND REEL 7"
Max Power Dissipation	75mW
Number of Functions	1
Depth	600μm
Case Code (Metric)	1608
Case Code (Imperial)	0603
Number of Elements	1
Configuration	Standard
Power Dissipation	75mW
Voltage - Forward (Vf) (Typ)	2V
Viewing Angle	130°
Optoelectronic Device Type	SINGLE COLOR LED
Forward Current	30mA
Current - Test	20mA
Lens Style	Rectangle with Flat Top
Lens Size	1.20mmx0.60mm
Luminous Intensity	54 mcd
Lens Transparency	Clear
Wavelength - Peak	639nm
Lens Color	Colorless
Reverse Voltage	5V
Wavelength - Dominant	631nm
Height	600μm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

LTST-S270KRKT Product Details

Description: The Lite-On LTST-S270KRKT is a discrete LED indication light with a red clear chip in a 0603 surface mount package.

Features:
- High brightness and wide viewing angle
- Low power consumption
- RoHS compliant
- High reliability
- Low thermal resistance

Applications: The LTST-S270KRKT is suitable for a variety of applications, including automotive, consumer electronics, industrial, and medical devices. It can be used as a status indicator, warning light, or backlight. It is also suitable for use in lighting applications such as decorative lighting, accent lighting, and task lighting.
