LSIC2SD120E30CC

  • LSIC2SD120E30CC - LSIC2SD120E30CC datasheet pdf and Diodes - Rectifiers - Single product details from Littelfuse Inc. stock available on our website
  • LSIC2SD120E30CC - LSIC2SD120E30CC datasheet pdf and Diodes - Rectifiers - Single product details from Littelfuse Inc. stock available on our website

LSIC2SD120E30CC

LSIC2SD120E30CC

Littelfuse Inc.

LSIC2SD120E30CC datasheet pdf and Diodes - Rectifiers - Single product details from Littelfuse Inc. stock available on our website

SOT-23

LSIC2SD120E30CC Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 23 Weeks
Mounting Type Through Hole
Package / Case TO-247-3
Series Gen2
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Peak Reflow Temperature (Cel) NOT SPECIFIED
[email protected] Reflow Temperature-Max (s) NOT SPECIFIED
Speed No Recovery Time > 500mA (Io)
Diode Type Silicon Carbide Schottky
Current - Reverse Leakage @ Vr 100μA @ 1200V
Voltage - Forward (Vf) (Max) @ If 1.8V @ 15A
Operating Temperature - Junction -55°C~175°C
Voltage - DC Reverse (Vr) (Max) 1200V
Current - Average Rectified (Io) 44A DC
Reverse Recovery Time 0ns
Capacitance @ Vr, F 920pF @ 1V 1MHz
RoHS StatusROHS3 Compliant
In-Stock:4164 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$20.00000$20
10$18.50000$185
25$17.00000$425
100$15.80000$1580
450$14.50000$6525

LSIC2SD120E30CC Product Details

LSIC2SD120E30CC Overview




LSIC2SD120E30CC Features



LSIC2SD120E30CC Applications


There are a lot of Littelfuse Inc. LSIC2SD120E30CC applications of single-phase diode rectifier.

  • Reverse Polarity Protection
  • Welders
  • Recirculating Diode
  • Polarity Protection Diode
  • Ultra High-Speed Switching
  • Freewheeling
  • DC motor control and drives
  • Power converters
  • Battery chargers
  • Switching Diode
