Name: MIC37102WR
Brand: Microchip Technology
SKU: MIC37102WR
Price: 2.14000 USD
Availability: InStock

new-10%

MIC37102WR

Manufacturer part number:MIC37102WR

Manufacturer:Microchip Technology

Description:Enable Adjustable 1.7 mm MIC37102 PMIC -- Series SPak-5 (5 leads + Tab)

Case Package:SOT-23

Datasheet:MIC37102WR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	13 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	SPak-5 (5 leads + Tab)
Surface Mount	YES
Number of Pins	5
Supplier Device Package	S-PAK-5
Number of Terminals	5
Mounting Style	SMD/SMT
Maximum Operating Temperature	+ 125 C
Minimum Operating Temperature	- 40 C
Manufacturer	Microchip
Brand	Microchip Technology
RoHS	Details
Product Status	Active
Mfr	Microchip Technology
Base Product Number	MIC37102
Package	Tube
Package Shape	RECTANGULAR
Operating Temperature	-40°C~125°C
Packaging	Tube
Published	2007
Series	--
Tolerance	1 %
JESD-609 Code	e3
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
ECCN Code	EAR99
Terminal Finish	Matte Tin (Sn) - annealed
Max Operating Temperature	125°C
Min Operating Temperature	-40°C
HTS Code	8542.39.00.01
Subcategory	PMIC - Power Management ICs
Terminal Position	SINGLE
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Number of Functions	1
Terminal Pitch	1.7 mm
Reach Compliance Code	not_compliant
Base Part Number	MIC37102
JESD-30 Code	R-PSSO-G5
Number of Outputs	1
Qualification Status	Not Qualified
Voltage - Input (Max)	6V
Output Voltage	6V
Output Type	Adjustable
Max Output Current	1A
Polarity	Positive
Output Configuration	Positive
Output Current	1 A
Current - Output	1A
Quiescent Current	25mA
Control Features	Enable
Voltage - Output (Min/Fixed)	1.24V
Number of Regulators	1
Min Input Voltage	2.25V
Protection Features	Over Current, Over Temperature
Voltage Dropout (Max)	0.5V @ 1A
Max Input Voltage	6V
PSRR	--
Reference Voltage	1.24V
Seated Height-Max	2.16 mm
Dropout Voltage	280mV
Product Type	LDO Voltage Regulators
Output Voltage1-Max	6 V
Output Voltage1-Min	1.24 V
Regulator Type	ADJUSTABLE POSITIVE SINGLE OUTPUT LDO REGULATOR
Output Current1-Max	1 A
Voltage - Output (Max)	6V
Dropout Voltage1-Max	0.5 V
Operating Temperature TJ-Max	125 °C
Input Bias Current	40nA
Line Regulation	0.06 %
Operating Temperature TJ-Min	-40 °C
Load Regulation	0.2 %
Product Category	LDO Voltage Regulators
Width	8 mm
Length	9.395 mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free
