Name: PIC18LF4221-I/P
Brand: Microchip Technology
SKU: PIC18LF4221-I/P
Availability: InStock

new-10%

PIC18LF4221-I/P

Manufacturer part number:PIC18LF4221-I/P

Manufacturer:Microchip Technology

Description:4KB 2K x 16 FLASH PIC 8-Bit Microcontroller PIC® 18F Series PIC18LF4221 40 Pin 40MHz 5V 40-DIP (0.600, 15.24mm)

Case Package:SOT-23

Datasheet:PIC18LF4221-I/P Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	6 Weeks
Mount	Through Hole
Mounting Type	Through Hole
Package / Case	40-DIP (0.600, 15.24mm)
Number of Pins	40
Supplier Device Package	40-PDIP
Interfaces	I2C/SPI/USART
Package	Tube
Base Product Number	PIC18LF4221
Mfr	Microchip Technology
Data Converters	A/D 13x10b
Product Status	Active
Operating Temperature	-40°C~85°C TA
Packaging	Tube
Series	PIC® 18F
Published	2007
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	40
ECCN Code	3A991.A.2
Terminal Finish	Matte Tin (Sn)
Max Power Dissipation	1W
Terminal Position	DUAL
Supply Voltage	5V
Frequency	40MHz
Base Part Number	PIC18LF4221
Pin Count	40
Supply Voltage-Max (Vsup)	5.5V
Power Supplies	2/5.5V
Interface	I2C, SPI, UART, USART
Memory Size	4kB
Oscillator Type	Internal
Number of I/O	36
Speed	40MHz
RAM Size	512 x 8
Voltage - Supply (Vcc/Vdd)	2V~5.5V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
Core Processor	PIC
Peripherals	Brown-out Detect/Reset, HLVD, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	4KB 2K x 16
Connectivity	I2C, SPI, UART/USART
Supply Current-Max	23mA
Bit Size	8
Data Converter	A/D 13x10b
Watchdog Timer	Yes
Access Time	40 μs
Has ADC	YES
DMA Channels	NO
Data Bus Width	8b
PWM Channels	YES
DAC Channels	NO
Number of Timers/Counters	4
EEPROM Size	256 x 8
On Chip Program ROM Width	16
CPU Family	PIC
Device Core	PIC
Length	51.75mm
Height Seated (Max)	6.35mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

PIC18LF4221-I/P Product Details

PIC18LF4221-I/P Overview

There is a 40-DIP (0.600, 15.24mm) package available. The board has 36 I/Os. Using the Mounting Type Through Hole, the MCU is mounted on PCB. A 8-Bit core is used in order to power the IC chip. The type of memory it uses for its program is FLASH. -40°C~85°C TA is the temperature range at which this Microcontroller operates. PIC® 18F-series components are electrical components. In the case of this Microcontroller, the memory size of the program is 4KB 2K x 16. Powered by a PIC Core processor. Microcontroller's a MICROCONTROLLER uPs/uCs/Peripheral IC. IC Chip terminations are 40. As a result, this Microcontroller comes with a 8-bit size. Input voltage for the chip is 5V volts. A total of NO DMA channels are available. This IC part has a memory size of 4kB. There are a number of alternatives to the base part number PIC18LF4221 that you can find. Performing well when operated at frequency 40MHz can be achieved. Using YES PWM channels, the device works. On the chip, there are 40 pins that can be accessed. It comes with 4 timers/counters that can be set up. The pins counted are 40. The device is powered by the the PIC CPU family that is embedded in it.
