Name: PIC18LF43K22T-I/MV
Brand: Microchip Technology
SKU: PIC18LF43K22T-I/MV
Availability: InStock

new-10%

PIC18LF43K22T-I/MV

Manufacturer part number:PIC18LF43K22T-I/MV

Manufacturer:Microchip Technology

Description:8KB 4K x 16 FLASH PIC 8-Bit Microcontroller PIC® XLP™ 18K Series PIC18LF43K22 40 Pin 64MHz 3V 40-UFQFN Exposed Pad

Case Package:SOT-23

Datasheet:PIC18LF43K22T-I/MV Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	16 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	40-UFQFN Exposed Pad
Number of Pins	40
Supplier Device Package	40-UQFN (5x5)
Interfaces	I2C/SPI/USART
Data Converters	A/D 30x10b
Package	Tape & Reel (TR)
Base Product Number	PIC18LF43
Mfr	Microchip Technology
Product Status	Active
Operating Temperature	-40°C~85°C TA
Packaging	Tape & Reel (TR)
Series	PIC® XLP™ 18K
Published	2012
JESD-609 Code	e3
Part Status	Active
Moisture Sensitivity Level (MSL)	2 (1 Year)
Number of Terminations	40
ECCN Code	3A001.A.3
Terminal Finish	Matte Tin (Sn)
Additional Feature	ALSO OPERATES 1.8 V MINIMUM SUPPLY AT 20 MHZ
HTS Code	8542.31.00.01
Max Power Dissipation	1W
Terminal Position	QUAD
Peak Reflow Temperature (Cel)	260
Supply Voltage	3V
Terminal Pitch	0.4mm
Frequency	64MHz
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	PIC18LF43K22
Pin Count	40
Supply Voltage-Max (Vsup)	3.6V
Power Supplies	2/3.3V
Interface	I2C, SPI, UART, USART
Memory Size	8kB
Oscillator Type	Internal
Number of I/O	35
Speed	64MHz
RAM Size	512 x 8
Voltage - Supply (Vcc/Vdd)	1.8V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	PIC
Peripherals	Brown-out Detect/Reset, HLVD, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	8KB 4K x 16
Connectivity	I2C, SPI, UART/USART
Supply Current-Max	12mA
Bit Size	8
Data Converter	A/D 30x10b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	NO
Data Bus Width	8b
PWM Channels	YES
DAC Channels	YES
Number of Timers/Counters	7
EEPROM Size	256 x 8
On Chip Program ROM Width	16
CPU Family	PIC
Number of Programmable I/O	36
Device Core	PIC
Length	5mm
Height Seated (Max)	0.55mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

PIC18LF43K22T-I/MV Product Details

PIC18LF43K22T-I/MV Overview

40-UFQFN Exposed Pad-packages are available. There are 35 I/O ports on this device. Device mounting type Surface Mount is the type of mounting that the Microcontroller uses. There is a 8-Bit core at the core of this MCU. There is a type of program memory called FLASH in the Microcontroller. There is a temperature range of -40°C~85°C TA for this Microcontroller. An electrical component of this type belongs to the PIC® XLP™ 18K series. This program memory has a size of 8KB 4K x 16, which indicates what the size of the program memory is. PIC Core processors are used in MCU. Devices of this type belong to the MICROCONTROLLER, RISC power supply/socket/peripheral ICs category. This chip has a total of 40 terminations on MCU chip. You get a 8-bit size. This Microcontroller chip is powered by 3V volts. There are NO DMA channels on this Microcontroller chip. The part has a memory size of 8kB. The base part number PIC18LF43K22 provides alternatives. This device is extremely efficient when operated at a frequency of 64MHz. Using the PWM channel YES, the device works with the motor. In this chip, 40 pins can be accessed. Using the timer/counter system, it has 7 timers/counters. It has 40 pins in total. In addition to this, the device is embedded with the the PIC CPU family. This device has 36 programmable input and output channels. Some of these features include ALSO OPERATES 1.8 V MINIMUM SUPPLY AT 20 MHZ, for example, as one example.
