WT21S

WT21S

WT21S

NKK Switches

SWITCH TOGGLE DPST 10A 125V

SOT-23

WT21S Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 16 Weeks
Contact MaterialCopper
Contact PlatingSilver
Mount Panel
Mounting Type Panel Mount
Actuator MaterialBrass, Chrome Plated
Operating Temperature-30°C~70°C
PackagingBulk
Published 2008
Series WT
JESD-609 Code e3
Feature Epoxy Sealed Terminals
Pbfree Code yes
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Terminal Finish Tin (Sn)
Voltage - Rated DC 30V
Current Rating (Amps) 10A AC/DC
Orientation Vertical
Ingress ProtectionIP67 - Dust Tight, Waterproof
Current Rating10A
Termination Style Solder Lug
Voltage - Rated AC 125V
Approval Agency CSA, UL
Actuator Type Standard Round
Circuit DPST
Switch FunctionOn-Off
Panel Cutout Dimensions Circular - 12.50mm Dia
Electrical Life 15,000 Cycles
Number of Poles 2
Illumination Non-Illuminated
Switch TypeTOGGLE SWITCH
Bushing ThreadM12 x 1
Length 28.8mm
Width 19.4mm
Actuator Length 17.50mm
RoHS StatusROHS3 Compliant
Lead Free Lead Free
Ratings Dust Tight, IP67, Waterproof
In-Stock:405 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$17.993537$17.993537
10$16.975035$169.75035
100$16.014185$1601.4185
500$15.107722$7553.861
1000$14.252567$14252.567

WT21S Product Details

The NKK Switches WT21S Toggle Switch is a double-pole single-throw (DPST) switch designed for use in a variety of applications. It is rated for 10A at 125V and is UL and CSA approved. It features a black plastic body with a silver-plated brass contact and a black plastic toggle actuator. The switch is designed to be panel-mounted and is suitable for use in a variety of applications, including lighting, motor control, and power distribution. It is also suitable for use in hazardous locations, such as those with flammable gases or dust. The WT21S is a reliable and durable switch that is easy to install and maintain.
