Name: MCF5249CVM140
Brand: NXP USA Inc.
SKU: MCF5249CVM140
Availability: InStock

new-10%

MCF5249CVM140

Manufacturer part number:MCF5249CVM140

Manufacturer:NXP USA Inc.

Description:ROMless Coldfire V2 32-Bit Microcontroller MCF524x Series MCF5249 1.8V 160-BGA

Case Package:SOT-23

Datasheet:MCF5249CVM140 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	10 Weeks
Mounting Type	Surface Mount
Package / Case	160-BGA
Surface Mount	YES
Operating Temperature	-40°C~85°C TA
Packaging	Tray
Series	MCF524x
Published	2001
JESD-609 Code	e1
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	160
ECCN Code	3A991.A.2
Terminal Finish	Tin/Silver/Copper (Sn/Ag/Cu)
Additional Feature	REQUIRES 3.3V SUPPLY FOR I/O
HTS Code	8542.31.00.01
Terminal Position	BOTTOM
Terminal Form	BALL
Peak Reflow Temperature (Cel)	260
Supply Voltage	1.8V
Terminal Pitch	1mm
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	MCF5249
JESD-30 Code	S-PBGA-B160
Qualification Status	Not Qualified
Oscillator Type	External
Number of I/O	47
Speed	140MHz
RAM Size	96K x 8
Voltage - Supply (Vcc/Vdd)	3V~3.6V
uPs/uCs/Peripheral ICs Type	MICROPROCESSOR, RISC
Core Processor	Coldfire V2
Peripherals	DMA, I2S, POR, Serial Audio, WDT
Clock Frequency	33.86MHz
Program Memory Type	ROMless
Core Size	32-Bit
Connectivity	I2C, IDE, Memory Card, SPI, UART/USART
Bit Size	32
Data Converter	A/D 4x12b
Address Bus Width	24
Boundary Scan	YES
Low Power Mode	YES
External Data Bus Width	16
Format	FIXED POINT
Integrated Cache	YES
Length	15mm
Height Seated (Max)	1.75mm
Width	15mm
RoHS Status	ROHS3 Compliant

MCF5249CVM140 Product Details

MCF5249CVM140 Overview
