74LCX16821MEA Overview
The package is in the form of 56-BSSOP (0.295, 7.50mm Width). A package named Tubeincludes it. Tri-State, Non-Invertedis the output configured for it. In the configuration of the trigger, Positive Edgeis used. There is an electric part mounted in the way of Surface Mount. The JK flip flop operates with an input voltage of 2V~3.6V volts. Temperature is set to -40°C~85°C TA. It belongs to the type D-Typeof flip flops. The FPGA belongs to the 74LCX series. Its output frequency should not exceed 150MHz. During its operation, it consumes 20μA quiescent energy. The 74LCX16821 family contains this object. Input capacitance of this device is 7pF farads. The electronic part is mounted in the way of Surface Mount. It is designed with 56 pins. It has a clock edge trigger type of Positive Edge. This flip flop is designed with 20 Bits. It operates with 3 output lines. A total of 2input lines have been provided.
74LCX16821MEA Features
Tube package
74LCX series
56 pins
20 Bits
74LCX16821MEA Applications
There are a lot of ON Semiconductor 74LCX16821MEA Flip Flops applications.
- Guaranteed simultaneous switching noise level
- Storage Registers
- Balanced Propagation Delays
- Computing
- Divide a clock signal by 2 or 4
- Set-reset capability
- Safety Clamp
- Parallel data storage
- Pattern generators
- Data Synchronizers
