Name: MBR560MFST1G
Brand: ON Semiconductor
SKU: MBR560MFST1G
Availability: InStock

new-10%

MBR560MFST1G

Manufacturer part number:MBR560MFST1G

Manufacturer:ON Semiconductor

Description:MBR560MFST1G datasheet pdf and Diodes - Rectifiers - Single product details from ON Semiconductor stock available on our website

Case Package:SOT-23

Datasheet:MBR560MFST1G Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	6 Weeks
Lifecycle Status	ACTIVE (Last Updated: 3 days ago)
Mounting Type	Surface Mount
Package / Case	8-PowerTDFN, 5 Leads
Surface Mount	YES
Number of Pins	5
Diode Element Material	SILICON
Packaging	Tape & Reel (TR)
Published	2013
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	5
Termination	SMD/SMT
ECCN Code	EAR99
Terminal Finish	Tin (Sn)
Max Operating Temperature	175°C
Min Operating Temperature	-55°C
Additional Feature	LOW POWER LOSS
Terminal Position	DUAL
Terminal Form	FLAT
Pin Count	5
Number of Elements	1
Element Configuration	Single
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Diode Type	Schottky
Current - Reverse Leakage @ Vr	150μA @ 60V
Voltage - Forward (Vf) (Max) @ If	780mV @ 5A
Case Connection	CATHODE
Forward Current	5A
Operating Temperature - Junction	-55°C~175°C
Output Current-Max	5A
Application	EFFICIENCY
Halogen Free	Halogen Free
Forward Voltage	650mV
Max Reverse Voltage (DC)	60V
Average Rectified Current	5A
Number of Phases	1
Peak Reverse Current	15μA
Max Repetitive Reverse Voltage (Vrrm)	60V
Peak Non-Repetitive Surge Current	100A
Max Forward Surge Current (Ifsm)	100A
Reverse Voltage (DC)	60V
Height	1mm
Length	5.8mm
Width	4.9mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

MBR560MFST1G Product Details

MBR560MFST1G Overview

There is an average rectified current of 5A volts for this device.The allowable value of forward current reaches 5A.The maximum output current is 5A.The datasheets show a peak reverse of 15μA, as shown in the data chart.
