SBT150-04J

Name: SBT150-04J
Brand: ON Semiconductor
SKU: SBT150-04J
Availability: InStock

new-10%

Manufacturer part number:SBT150-04J

Manufacturer:ON Semiconductor

Description:SBT150-04J datasheet pdf and Diodes - Rectifiers - Arrays product details from ON Semiconductor stock available on our website

Case Package:SOT-23

Datasheet:SBT150-04J Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Through Hole
Mounting Type	Through Hole
Package / Case	TO-220-3 Full Pack
Number of Pins	3
Diode Element Material	SILICON
Packaging	Bulk
Published	2005
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	3
ECCN Code	EAR99
Terminal Finish	Tin/Copper/Silver/Nickel (Sn/Cu/Ag/Ni)
Additional Feature	HIGH RELIABILITY, LOW NOISE
HTS Code	8541.10.00.80
Terminal Position	SINGLE
Pin Count	3
Number of Elements	2
Element Configuration	Common Cathode
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Diode Type	Schottky
Current - Reverse Leakage @ Vr	200μA @ 20V
Voltage - Forward (Vf) (Max) @ If	550mV @ 6A
Operating Temperature - Junction	-55°C~150°C
Output Current-Max	7.5A
Application	GENERAL PURPOSE
Max Reverse Voltage (DC)	40V
Average Rectified Current	15A
Number of Phases	1
JEDEC-95 Code	TO-220AB
Non-rep Pk Forward Current-Max	100A
Diode Configuration	1 Pair Common Cathode
RoHS Status	RoHS Compliant
Lead Free	Lead Free
