Name: LNJ837W83RA
Brand: Panasonic Electronic Components
SKU: LNJ837W83RA
Availability: InStock

new-10%

LNJ837W83RA

Manufacturer part number:LNJ837W83RA

Manufacturer:Panasonic Electronic Components

Description:Standard LEDs - SMD LED ORG HI-BRT ESS

Case Package:SOT-23

Datasheet:LNJ837W83RA Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	14 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	0603 (1608 Metric)
Number of Pins	2
Shape	RECTANGULAR
Packaging	Tape & Reel (TR)
Published	2009
Size / Dimension	1.60mm Lx0.80mm W
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	2
Max Operating Temperature	85°C
Min Operating Temperature	-30°C
Color	Orange
Subcategory	Visible LEDs
Packing Method	BULK
Number of Functions	1
Reach Compliance Code	unknown
Base Part Number	LNJ*37
Case Code (Metric)	1608
Case Code (Imperial)	0603
Configuration	Standard
Voltage - Forward (Vf) (Typ)	1.95V
Optoelectronic Device Type	SINGLE COLOR LED
Forward Current	5mA
Lens Style	Rectangle with Flat Top
Lens Size	1.10mmx0.80mm
Luminous Intensity	17.5 mcd
Millicandela Rating	17.5mcd
Wavelength - Peak	630nm
Wavelength - Dominant	620nm
Number of LEDs	1
Reverse Voltage-Max	4V
Height	200μm
REACH SVHC	Yes
RoHS Status	RoHS Compliant
Lead Free	Lead Free

LNJ837W83RA Product Details

Description:

The Panasonic LED Indication - Discrete LNJ837W83RA is a standard LED with a surface mount design. It is a high brightness LED with an orange color. It is designed for use in a variety of applications.

Features:
• High brightness LED with an orange color
• Surface mount design
• Low power consumption
• Long life
• RoHS compliant

Applications:
The Panasonic LED Indication - Discrete LNJ837W83RA is suitable for a variety of applications, including automotive, industrial, and consumer electronics. It can be used for backlighting, signal indication, and decorative lighting.
