MA3D749

Name: MA3D749
Brand: Panasonic Electronic Components
SKU: MA3D749
Availability: InStock

new-10%

MA3D749

Manufacturer part number:MA3D749

Manufacturer:Panasonic Electronic Components

Description:MA3D749 datasheet pdf and Diodes - Rectifiers - Arrays product details from Panasonic Electronic Components stock available on our website

Case Package:SOT-23

Datasheet:MA3D749 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Through Hole
Package / Case	TO-220-3 Full Pack
Surface Mount	NO
Diode Element Material	SILICON
Packaging	Bulk
Published	2004
Pbfree Code	yes
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	3
ECCN Code	EAR99
HTS Code	8541.10.00.80
Subcategory	Rectifier Diodes
Terminal Position	SINGLE
Peak Reflow Temperature (Cel)	260
[email protected] Reflow Temperature-Max (s)	10
JESD-30 Code	R-PSFM-T3
Qualification Status	Not Qualified
Operating Temperature (Max)	125°C
Number of Elements	2
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Diode Type	Schottky
Current - Reverse Leakage @ Vr	1mA @ 40V
Voltage - Forward (Vf) (Max) @ If	550mV @ 2.5A
Case Connection	ISOLATED
Operating Temperature - Junction	-40°C~125°C
Output Current-Max	5A
Application	GENERAL PURPOSE
Voltage - DC Reverse (Vr) (Max)	40V
Current - Average Rectified (Io)	5A
Number of Phases	1
Rep Pk Reverse Voltage-Max	40V
JEDEC-95 Code	TO-220AB
Non-rep Pk Forward Current-Max	90A
Diode Configuration	1 Pair Common Cathode
RoHS Status	RoHS Compliant
