Name: 1700325
Brand: Phoenix Contact
SKU: 1700325
Price: 2.87000 USD
Availability: InStock

new-10%

1700325

Manufacturer part number:1700325

Manufacturer:Phoenix Contact

Description:5mm Green Bulk Polyamide (PA), Nylon Through Hole Horizontal with Board Screw - Pressure Clip 14-24 AWG COMBICON FRONT

Case Package:SOT-23

Datasheet:1700325 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Contact Material	Tin
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	Polyamide (PA), Nylon
Weight	3.561012g
Packaging	Bulk
Series	COMBICON FRONT
Published	2011
Feature	Interlocking (Side)
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
Connector Type	Screw
Color	Green
Number of Rows	1
Gender	Female
Voltage - Rated	320V
Additional Feature	PA, 94V-0
HTS Code	8536.69.40.40
Pitch	5mm
Orientation	Straight
Depth	19.5mm
Current Rating	24A
Wire Gauge	14-24 AWG
ELV	Compliant
Max Supply Voltage	250V
Max Current Rating	24A
Wire Gauge (Max)	24 AWG
Wire Gauge (Min)	14 AWG
Number of Decks	1
Terminal and Terminal Block Type	MODULAR TERMINAL BLOCK
Torque - Screw	0.4-0.5 Nm (3.5-4.4 Lb-In)
Number of Ways	1
Safety Approval	UL
Mating Orientation	Horizontal with Board
Wire Termination	Screw - Pressure Clip
Screw Thread	M2.5
Number of Positions Per Level	1
Height	22mm
Length	5mm
Width	23.5mm
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1700325 Product Details

1700325 Overview

A Screw package is included with it.Its mounting type is Through Hole.Packaging is performed using a Bulk case.It is part of the COMBICON FRONT Series of products.Additionally, there are other features, such as PA, 94V-0.A number of features make it more powerful because of its Interlocking (Side) feature.Through Hole mounts the part.This chip should not be supplied with a voltage greater than 250V.
