Name: 1702473
Brand: Phoenix Contact
SKU: 1702473
Price: 0.54000 USD
Availability: InStock

new-10%

1702473

Manufacturer part number:1702473

Manufacturer:Phoenix Contact

Description:0.098 2.50mm Black Tape & Reel (TR) Liquid Crystal Polymer (LCP) Surface Mount Horizontal with Board Screwless - Spring Cage, Tension Clamp 1 Levels 20-26 AWG COMBICON PTSM

Case Package:SOT-23

Datasheet:1702473 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	7 Weeks
Contact Material	Copper
Contact Plating	Tin
Mount	Surface Mount
Mounting Type	Surface Mount
Material	Polymer
Housing Material	Liquid Crystal Polymer (LCP)
Packaging	Tape & Reel (TR)
Series	COMBICON PTSM
Published	2011
Feature	Solder Retention
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
Color	Black
Number of Rows	1
Gender	Female
Voltage - Rated	160V
Additional Feature	STANDARD: UL 94V-0, LCP
HTS Code	8536.69.40.40
Pitch	0.098 2.50mm
Orientation	Right Angle
Depth	9.4mm
Current Rating	6A
Voltage - Rated AC	32V
Wire Gauge	20-26 AWG
Max Supply Voltage	150V
Max Current Rating	6A
Number of Levels	1
Current	5A
Wire Gauge (Max)	20 AWG
Wire Gauge (Min)	24 AWG
Number of Decks	1
Terminal and Terminal Block Type	BARRIER STRIP TERMINAL BLOCK
Number of Ways	2
Safety Approval	EAC; UL
Mating Orientation	Horizontal with Board
Wire Termination	Screwless - Spring Cage, Tension Clamp
Number of Positions Per Level	2
Fastening Method	SPRING LOADED
Height	9.4mm
Length	5.5mm
Width	9mm
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1702473 Product Details

1702473 Overview

The device's mounting type is Surface Mount.In order to package the product, a Tape & Reel (TR) case is used.It belongs to the COMBICON PTSM Series of products.In addition, there are other features such as STANDARD: UL 94V-0, LCP, to mention only a few.Its Solder Retention feature renders it more powerful in many ways.The part is mounted by Surface Mount.The supply voltage of this chip should not exceed 150V.
