Name: 1757491
Brand: Phoenix Contact
SKU: 1757491
Price: 1.60000 USD
Availability: InStock

new-10%

1757491

Manufacturer part number:1757491

Manufacturer:Phoenix Contact

Description:1757491 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

Case Package:SOT-23

Datasheet:1757491 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	7 Weeks
Contact Plating	Tin
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	Polyamide (PA), Nylon
Weight	2.113003g
Packaging	Bulk
Published	2005
Series	COMBICON MSTBA
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Connector Type	Plug
Type	Header, Male Pins, Shrouded (4 Side)
Min Operating Temperature	-40°C
Color	Green
Number of Rows	1
Gender	Male
Voltage - Rated	320V
Pitch	0.197 5.00mm
Orientation	Right Angle
Depth	12mm
Insulation Height	0.339 8.61mm
Current Rating	12A
Termination Style	Solder
Approval Agency	CSA, UL
Voltage	300V
Contact Tail Length	0.138 3.50mm
Max Current Rating	12A
Number of Levels	1
Current	15A
Number of Poles	4
Number of Decks	1
Voltage - IEC	400V
Number of Ways	4
Safety Approval	UL
Header Orientation	90°, Right Angle
Fastening Method	CONNECTOR
Height	8.75mm
Length	22mm
Width	22mm
Material Flammability Rating	UL94 V-0
REACH SVHC	No SVHC
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1757491 Product Details

1757491 Overview

The packaging is Plug.Mounting type Through Hole is assigned to the device.We use a Bulk case to package the product.There is a product in the COMBICON MSTBA Series.A minimum temperature of -40°C is needed for this device.You've got Through Hole mounted on the part.There are a lot of similarities between this part and other Header, Male Pins, Shrouded (4 Side) products.
