Name: 1759114
Brand: Phoenix Contact
SKU: 1759114
Price: 4.25000 USD
Availability: InStock

new-10%

1759114

Manufacturer part number:1759114

Manufacturer:Phoenix Contact

Description:1759114 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

Case Package:SOT-23

Datasheet:1759114 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	7 Weeks
Contact Plating	Tin
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	Polyamide (PA), Nylon
Weight	151.999994g
Packaging	Bulk
Published	2010
Series	COMBICON MSTB
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Type	Header, Male Pins, Shrouded (2 Side)
Number of Positions	12
Color	Green
Number of Rows	1
Gender	Male
Voltage - Rated	250V
Additional Feature	STANDARD: UL 94V-0, PA, SAFETY APPROVAL :VDE
HTS Code	8536.69.40.40
Voltage - Rated DC	320V
Pitch	0.200 5.08mm
Orientation	Right Angle
Depth	12mm
Insulation Height	0.339 8.61mm
Current Rating	12A
Termination Style	Solder
Approval Agency	CSA, EN, UL, VDE
Voltage	300V
Contact Tail Length	0.138 3.50mm
Max Current Rating	12A
Number of Levels	1
Current	15A
Number of Poles	12
Number of Decks	1
Voltage - IEC	400V
Number of Ways	12
Safety Approval	CB; CCA; CSA; CUL; EAC; UL
Header Orientation	90°, Right Angle
Fastening Method	CONNECTOR
Length	40.64mm
Width	60.96mm
Thickness	55.88mm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1759114 Product Details

1759114 Overview

Mounting type Through Hole is assigned to the device.We pack the product in a Bulk case.It's from the COMBICON MSTB Series.Additionally, there are other features such as STANDARD: UL 94V-0, PA, SAFETY APPROVAL :VDE.Part Through Hole is mounted to the part.There are a lot of advantages this part has in common with other Header, Male Pins, Shrouded (2 Side) parts.
