Name: 1772618
Brand: Phoenix Contact
SKU: 1772618
Price: 3.97000 USD
Availability: InStock

new-10%

1772618

Manufacturer part number:1772618

Manufacturer:Phoenix Contact

Description:1772618 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

Case Package:SOT-23

Datasheet:1772618 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Mount	Free Hanging
Mounting Type	Free Hanging (In-Line)
Material	Polyamide, Tin
Housing Material	Polyamide (PA), Nylon
Packaging	Bulk
Published	2011
Series	COMBICON TFMC
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Screwless
ECCN Code	EAR99
Type	Plug, Female Sockets
Number of Positions	2
Color	Green
Gender	Female
Voltage - Rated	160V
HTS Code	8536.69.40.40
Pitch	0.138 3.50mm
Insulation Height	0.902 22.90mm
Current Rating	8A
Termination Style	Screwless - Leg Spring, Push-In Spring
Voltage	300V
Number of Levels	1 (Mate), 2 (Input)
Current	8A
Wire Gauge (Max)	16 AWG
Wire Gauge (Min)	24 AWG
Contact Mating Finish	Tin
Wire Gauge or Range - AWG	16-24 AWG
Voltage - IEC	320V
Positions Per Level	2 (Mate), 4 (Input)
Plug Wire Entry	180°
Wire Gauge or Range - mm²	0.2-1.5mm2
Wire Strip Length	10mm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant

1772618 Product Details

1772618 Overview

Mounting type is Free Hanging (In-Line).It's packaged in a Bulk case.COMBICON TFMC Series product.Free Hanging is the mounting point for the part.In addition to its benefits, this part also shares many with the other products in the Plug, Female Sockets series.
