Name: 1776139
Brand: Phoenix Contact
SKU: 1776139
Price: 6.36000 USD
Availability: InStock

new-10%

1776139

Manufacturer part number:1776139

Manufacturer:Phoenix Contact

Description:1776139 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

Case Package:SOT-23

Datasheet:1776139 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Mount	Free Hanging
Mounting Type	Free Hanging (In-Line)
Packaging	Bulk
Published	2011
Series	COMBICON MSTB
Feature	Retention Latches (Non-Wire Side), Strain Relief
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Connector Type	Screw
Type	Plug, Female Sockets
Number of Positions	4
Color	Black
Number of Rows	1
Voltage - Rated	250V
Pitch	0.200 5.08mm
Current Rating	12A
Termination Style	Screw - Rising Cage Clamp
Voltage	300V
Number of Levels	1
Current	10A
Wire Gauge (Max)	12 AWG
Wire Gauge (Min)	24 AWG
Contact Mating Finish	Tin
Number of Decks	1
Wire Gauge or Range - AWG	12-30 AWG
Torque - Screw	0.5-0.6 Nm (4.4-5.3 Lb-In)
Number of Ways	4
Safety Approval	CB; CSA; CUL; GOST; UL; VDE
Plug Wire Entry	180°
Wire Gauge or Range - mm²	0.2-2.5mm2
Wire Strip Length	7mm
Screw Size	M3
Wire Cross Section	2.5 mm2
RoHS Status	RoHS Compliant

1776139 Product Details

1776139 Overview

Packaging is in the form of Screw.Its mounting type is Free Hanging (In-Line).An Bulk case is utilized for packaging the product.Specifically, it is one of the products in the COMBICON MSTB Series.A number of benefits can be derived from the Retention Latches (Non-Wire Side), Strain Relief feature of this application.This part is mounted by Free Hanging. There are many benefits that this part shares with other Plug, Female Sockets products as well.
