Name: 1789621
Brand: Phoenix Contact
SKU: 1789621
Price: 1.83000 USD
Availability: InStock

new-10%

1789621

Manufacturer part number:1789621

Manufacturer:Phoenix Contact

Description:3.81mm Green Bulk Polyamide (PA), Nylon Through Hole Vertical with Board Screwless - Spring Cage, Tension Clamp 16-26 AWG COMBICON FFKDSA

Case Package:SOT-23

Datasheet:1789621 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	Polyamide (PA), Nylon
Weight	1.263g
Packaging	Bulk
Series	COMBICON FFKDSA
Published	2011
Feature	Interlocking (Side), Lever Actuated
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Screwless
ECCN Code	EAR99
Color	Green
Voltage - Rated	160V
HTS Code	8536.69.40.40
Pitch	3.81mm
Depth	6.35mm
Current Rating	12A
Number of Contacts	1
Wire Gauge	16-26 AWG
Voltage	300V
Max Current Rating	12A
Current	6A
Wire Gauge (Max)	26 AWG
Wire Gauge (Min)	16 AWG
Terminal and Terminal Block Type	MODULAR TERMINAL BLOCK
Mating Orientation	Vertical with Board
Wire Termination	Screwless - Spring Cage, Tension Clamp
Width	6.35mm
RoHS Status	RoHS Compliant
Lead Free	Lead Free

1789621 Product Details

1789621 Overview

The device's mounting type is Through Hole.In order to package the product, a Bulk case is used.It belongs to the COMBICON FFKDSA Series of products.Its Interlocking (Side), Lever Actuated feature renders it more powerful in many ways.The part is mounted by Through Hole.
