Name: 1829251
Brand: Phoenix Contact
SKU: 1829251
Price: 9.12000 USD
Availability: InStock

new

1829251

Manufacturer part number:1829251

Manufacturer:Phoenix Contact

Description:Bulk 0.300 7.62mm Green 1 Levels Through Hole Header, Male Pins, Shrouded (4 Side) COMBICON GMSTBV Polyamide (PA), Nylon

Case Package:SOT-23

Datasheet:1829251 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Contact Plating	Tin
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	Polyamide (PA), Nylon
Weight	176.999992g
Packaging	Bulk
Published	2011
Series	COMBICON GMSTBV
Feature	Mating and Mounting Flange
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Connector Type	Plug
Type	Header, Male Pins, Shrouded (4 Side)
Number of Positions	12
Color	Green
Number of Rows	1
Voltage - Rated	400V
Additional Feature	PA, 94V-0
HTS Code	8536.69.40.40
Pitch	0.300 7.62mm
Insulation Height	0.472 12.00mm
Current Rating	12A
Termination Style	Solder
Voltage	300V
Contact Tail Length	0.154 3.90mm
Number of Levels	1
Current	10A
Voltage - UL	300V
Number of Decks	1
Current - UL	15A
Voltage - IEC	630V
Number of Ways	12
Safety Approval	UL
Header Orientation	Vertical
Height	15.9mm
Length	8.6mm
Width	102.02mm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

1829251 Product Details

1829251 Overview

Currently, it is packaged in Plug.Mounting type Through Hole is assigned to the device.Packaging the product involves using a Bulk case.Among the products in the COMBICON GMSTBV Series, it is one of the most popular.There are also other features, like PA, 94V-0, to name a few.A number of benefits can be derived from the Mating and Mounting Flange feature of this application.Through Hole is the mounting point for the part.There are a lot of advantages this part has in common with other Header, Male Pins, Shrouded (4 Side) parts.
