Name: 1848122
Brand: Phoenix Contact
SKU: 1848122
Price: 12.99000 USD
Availability: InStock

new

1848122

Manufacturer part number:1848122

Manufacturer:Phoenix Contact

Description:1848122 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

Case Package:SOT-23

Datasheet:1848122 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Contact Material	NOT SPECIFIED
Contact Plating	Silver
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	Polyamide (PA), Nylon
Packaging	Bulk
Published	1999
Series	POWER SUBCON
JESD-609 Code	e3
Feature	Board Lock, DB9 Shape, Mating Flange
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Connector Type	Plug
Type	Header, Male Pins, Shrouded (4 Side)
Color	Green
Gender	Male
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.138 3.50mm
Total Number of Contacts	3
Orientation	Right Angle
Insulation Height	0.539 13.70mm
Reach Compliance Code	not_compliant
Current Rating	8A
Termination Style	Solder
UL Flammability Code	94V-0
Empty Shell	NO
Voltage	300V
Contact Tail Length	0.138 3.50mm
Shell Size	1/E
Max Current Rating	8A
Number of Levels	1
Current	8A
Contact Mating Finish	Tin
Voltage - IEC	250V
Header Orientation	90°, Right Angle
Number of Positions Per Level	3
Height	20.8mm
Length	30.8mm
Width	30.8mm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1848122 Product Details

1848122 Overview

Currently, it is packaged in Plug.This device is mounted in the Through Hole position.It has been determined that a Bulk case is necessary to package the product.The product is part of the POWER SUBCON Series.Several benefits come from the Board Lock, DB9 Shape, Mating Flange feature.Part Through Hole is mounted to the part.In addition to its benefits, this part also shares many with the other products in the Header, Male Pins, Shrouded (4 Side) series.
