Name: 1873061
Brand: Phoenix Contact
SKU: 1873061
Price: 3.88000 USD
Availability: InStock

new-10%

1873061

Manufacturer part number:1873061

Manufacturer:Phoenix Contact

Description:1873061 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

Case Package:SOT-23

Datasheet:1873061 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	7 Weeks
Contact Material	Copper
Mount	Cable, Free Hanging
Mounting Type	Free Hanging (In-Line)
Housing Material	Polyamide (PA), Nylon
Weight	207.999998g
Packaging	Bulk
Published	2010
Series	COMBICON FKC
Feature	Retention Latches (Non-Wire Side)
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Screwless
ECCN Code	EAR99
Connector Type	Socket
Type	Plug, Female Sockets
Color	Green
Number of Rows	1
Voltage - Rated	250V
Additional Feature	PA, 94V-0
Pitch	0.200 5.08mm
Orientation	Straight
Insulation Height	0.591 15.00mm
Current Rating	12A
Termination Style	Screwless - Leg Spring, Push-In Spring
Approval Agency	CB, VDE, cULus
Contact Gender	Female
Voltage	300V
Max Current Rating	12A
Number of Levels	1
Current	10A
Wire Gauge (Max)	12 AWG
Wire Gauge (Min)	24 AWG
Contact Mating Finish	Tin
Number of Decks	1
Wire Gauge or Range - AWG	12-26 AWG
Voltage - IEC	630V
Number of Ways	3
Safety Approval	UL
Plug Wire Entry	180°
Wire Gauge or Range - mm²	0.2-2.5mm2
Wire Strip Length	10mm
Number of Positions Per Level	3
Wire Cross Section	2.5 mm2
Fastening Method	SPRING LOADED
Test Voltage	4kV
Height	15.86mm
Length	15mm
Width	25.6mm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1873061 Product Details

1873061 Overview

This product is packaged in a Socket box.It's mounted Free Hanging (In-Line).A Bulk case is used for packaging.The product is a part of the COMBICON FKC Series.Additionally, there are features like PA, 94V-0, just to name a few.A number of advantages can be derived from its Retention Latches (Non-Wire Side) feature.Part Cable, Free Hanging is mounted to the part.As with other Plug, Female Sockets products, this part has a lot of benefits.
