1912139

1912139

1912139

Phoenix Contact

1912139 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

SOT-23

1912139 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 4 Weeks
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material Polyamide, Tin
Housing Material Polyamide (PA), Nylon
Weight 14.399999g
PackagingBulk
Published 2001
Series COMBICON MSTB
Feature Mating Flange
Pbfree Code yes
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Screw
Type Plug, Female Sockets
Color Green
Number of Rows 1
Gender Female
Voltage - Rated 250V
Additional FeaturePA, UL 94V0
Pitch 0.197 5.00mm
Insulation Height 0.591 15.00mm
Reach Compliance Code unknown
Current Rating16A
Termination Style Screw - Rising Cage Clamp
Voltage 300V
Number of Levels 1
Current 16A
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 12 AWG
Contact Mating Finish Tin
Voltage - UL 300V
Number of Decks 1
Wire Gauge or Range - AWG 12-30 AWG
Voltage - IEC 630V
Torque - Screw 0.5-0.6 Nm (4.4-5.3 Lb-In)
Number of Ways 8
Safety Approval UL
Plug Wire Entry 180°
Wire Gauge or Range - mm² 0.2-2.5mm2
Wire Strip Length 7mm
Number of Positions Per Level 8
Screw Size M3
Wire Cross Section 2.5 mm2
Material Flammability Rating UL94 V-0
RoHS StatusRoHS Compliant
Flammability Rating UL94 V-0
In-Stock:602 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$9.90000$9.9
10$9.62900$96.29
50$8.99880$449.94
100$8.27880$827.88
250$7.64892$1912.23
500$7.28898$3644.49

1912139 Product Details

1912139 Overview


Packaging for this item is Screw.Free Hanging (In-Line) is the mounting type.We package the product with a Bulk case.This product is part of the COMBICON MSTB Series.There are also features like PA, UL 94V0, just to name a few.In many ways, it is more powerful due to its Mating Flange feature.It is mounted by Free Hanging.There are a number of benefits that this part has in common with other Plug, Female Sockets products.

1912139 Features


COMBICON MSTB series

1912139 Applications


There are a lot of Phoenix Contact 1912139 Terminal Blocks applications.

  • Telecommunications
  • Measuring & Control Technology
  • Automotive Electronics
  • Industrial Automation
  • Data Technology
  • Blowers
  • All Electrical Machinery
  • Communication
  • Refrigeration control
  • Anywhere power is distributed
