Home

1985234

  • 1985234 - 0.138 3.50mm Green Bulk Polyamide (PA), Nylon Through Hole 45° (135°) Angle with Board Screwless - Spring Cage, Tension Clamp 1 Levels 16-24 AWG COMBICON PTSA
  • 1985234 - 0.138 3.50mm Green Bulk Polyamide (PA), Nylon Through Hole 45° (135°) Angle with Board Screwless - Spring Cage, Tension Clamp 1 Levels 16-24 AWG COMBICON PTSA

1985234

1985234

Phoenix Contact

0.138 3.50mm Green Bulk Polyamide (PA), Nylon Through Hole 45° (135°) Angle with Board Screwless - Spring Cage, Tension Clamp 1 Levels 16-24 AWG COMBICON PTSA

SOT-23

1985234 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 13 Weeks
Contact MaterialCopper
Contact PlatingTin
Mount Through Hole
Mounting Type Through Hole
Insulation Material Nylon
Housing Material Polyamide (PA), Nylon
Weight 3.299998g
PackagingBulk
Series COMBICON PTSA
Published 2005
Pbfree Code yes
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screwless
ECCN Code EAR99
Color Green
Number of Rows 1
Voltage - Rated 250V
Pitch 0.138 3.50mm
Current Rating2A
Approval Agency UL, VDE
Number of Contacts 6
Wire Gauge16-24 AWG
Voltage 300V
Max Current Rating 2A
Number of Levels 1
Wire Gauge (Max) 24 AWG
Wire Gauge (Min) 20 AWG
Wire/Cable Gauge 16 AWG
Number of Decks 1
Terminal and Terminal Block Type MODULAR TERMINAL BLOCK
Number of Ways 6
Safety Approval UL; CSA
Mating Orientation 45° (135°) Angle with Board
Wire TerminationScrewless - Spring Cage, Tension Clamp
Stripping Length 8mm
Height 13.1mm
Length 12mm
Width 17.5mm
RoHS StatusRoHS Compliant
Flammability Rating UL94 V-2
Lead Free Lead Free
In-Stock:6387 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$0.85000$0.85
10$0.80900$8.09
50$0.78640$39.32
100$0.73500$73.5
250$0.67620$169.05
500$0.62476$312.38

1985234 Product Details

1985234 Overview


Through Hole is the type of mounting for the device.To package the product, a Bulk case is used.The product is a member of the COMBICON PTSA Series.It is mounted by Through Hole.

1985234 Features


COMBICON PTSA series


1985234 Applications


There are a lot of Phoenix Contact
1985234 Terminal Blocks applications.


  • Embedded systems
  • Datacom
  • Communication
  • Medical technology
  • Military Technology
  • Measuring & Control Technology
  • Instrumentation
  • Automotive Electronics
  • Telecommunications
  • Data Technology
