3212688

3212688

3212688

Phoenix Contact

3212688 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

SOT-23

3212688 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 4 Weeks
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material Polyamide
Housing Material Polyamide (PA), Nylon
PackagingBulk
Published 2012
Series CLIPLINE COMBI PP-H
Feature Interlocking (Side)
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screwless
ECCN Code EAR99
Connector Type Push-In
Type Plug, Female Sockets
Color Gray
Voltage - Rated 500V
HTS Code8536.69.40.40
Pitch 1.5mm
Insulation Height 1.232 31.30mm
Current Rating17.5A
Termination Style Screwless - Push-In Spring
Voltage 600V
Number of Levels 1
Current 5A
Wire Gauge (Max) 26 AWG
Wire Gauge (Min) 14 AWG
Wire Gauge or Range - AWG 14-26 AWG
Voltage - IEC 500V
Plug Wire Entry 180°
Wire Gauge or Range - mm² 0.14-1.5mm2
Wire Strip Length 10mm
Current - IEC 17.5A
Width 3.5mm
Material Flammability Rating UL94 V-0
RoHS StatusRoHS Compliant
In-Stock:4010 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$0.688695$0.688695
10$0.649712$6.49712
100$0.612936$61.2936
500$0.578242$289.121
1000$0.545511$545.511

3212688 Product Details

3212688 Overview


Packaging for this item is Push-In.Free Hanging (In-Line) is the mounting type.We pack the product in a Bulk case.Product number CLIPLINE COMBI PP-H belongs to the CLIPLINE COMBI PP-H Series.In many ways, it is more powerful due to its Interlocking (Side) feature.There's a Free Hanging mount on the part.

3212688 Features


CLIPLINE COMBI PP-H series

3212688 Applications


There are a lot of Phoenix Contact 3212688 Terminal Blocks applications.

  • Medical technology
  • Measuring & Control Technology
  • Automotive Electronics
  • Blowers
  • Electrical substations
  • Data Technology
  • Energy efficient lighting (LED)
  • Instrumentation
  • All Electrical Machinery
  • LED municipal outdoor and street lighting
