5441731

5441731

5441731

Phoenix Contact

5441731 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

SOT-23

5441731 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 9 Weeks
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Polyamide (PA), Nylon
PackagingBulk
Published 2015
Series BCP
Feature Retention Latches (Non-Wire Side)
Pbfree Code yes
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Plug, Female Sockets
Number of Positions 3
Color Black
Number of Rows 1
Pitch 0.197 5.00mm
Insulation Height 0.591 15.00mm
Current Rating12A
Termination Style Screw
Voltage 300V
Number of Levels 1
Current 15A
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 12 AWG
Contact Mating Finish Tin
Number of Decks 1
Wire Gauge or Range - AWG 12-30 AWG
Voltage - IEC 630V
Torque - Screw 0.4-0.5 Nm (3.5-4.4 Lb-In)
Number of Ways 3
Plug Wire Entry 180°
Wire Gauge or Range - mm² 0.2-2.5mm2
Wire Strip Length 7mm
Current - IEC 12A
Screw Size M3
Material Flammability Rating UL94 V-0
RoHS StatusRoHS Compliant
In-Stock:1837 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$0.238671$0.238671
10$0.225162$2.25162
100$0.212417$21.2417
500$0.200393$100.1965
1000$0.189050$189.05

5441731 Product Details

5441731 Overview


Free Hanging (In-Line) is the mount type.We use a Bulk case to package the product.This product is part of the BCP Series.This feature makes it more powerful in a number of ways due to its Retention Latches (Non-Wire Side) feature.There is a mounting hole at Free Hanging.

5441731 Features


BCP series

5441731 Applications


There are a lot of Phoenix Contact 5441731 Terminal Blocks applications.

  • Automotive Electronics
  • LED municipal outdoor and street lighting
  • Control panels
  • Military Technology
  • Datacom
  • Telecommunications
  • Embedded systems
  • Communication
  • Electrical substations
  • All Electrical Machinery
