Name: 1N5935BG
Brand: Rochester Electronics, LLC
SKU: 1N5935BG
Availability: InStock

new-10%

1N5935BG

Manufacturer part number:1N5935BG

Manufacturer:Rochester Electronics, LLC

Description:ZENER DIODE 23Ohm ±5% 1μA @ 20.6V -65°C~200°C 2 Terminations DO-204AL, DO-41, Axial

Case Package:SOT-23

Datasheet:1N5935BG Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Through Hole
Package / Case	DO-204AL, DO-41, Axial
Surface Mount	NO
Diode Element Material	SILICON
Operating Temperature	-65°C~200°C
Packaging	Bulk
Tolerance	±5%
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
Terminal Finish	MATTE TIN
Terminal Form	WIRE
Peak Reflow Temperature (Cel)	260
Time@Peak Reflow Temperature-Max (s)	40
Pin Count	2
JESD-30 Code	O-PALF-W2
Qualification Status	COMMERCIAL
Number of Elements	1
Polarity	UNIDIRECTIONAL
Configuration	SINGLE
Power Dissipation-Max	1W
Diode Type	ZENER DIODE
Current - Reverse Leakage @ Vr	1μA @ 20.6V
Voltage - Forward (Vf) (Max) @ If	1.5V @ 200mA
Case Connection	ISOLATED
Power - Max	3W
Impedance-Max	23Ohm
Reference Voltage	27V
Voltage - Zener (Nom) (Vz)	27V
Voltage Tol-Max	5%
Working Test Current	13.9mA
RoHS Status	ROHS3 Compliant

1N5935BG Product Details

1N5935BG Overview

The reverse leakage current for this electrical device is 1μA @ 20.6V.Voltage (Tol) 5% is the maximum possible.In the course of operation, Zener (Nom) drops to zero voltage.This device should be operated with a 13.9mA working test voltage.This value reaches 1.5V @ 200mA when the maximum Forward voltage (Vf) is applied.

1N5935BG Features

reverse leakage current of 1μA @ 20.6V
1μA @ 20.6V is the maximum voltage (Tol)
the working test voltage to 13.9mA
minimal dynamic impedance is 13.9mA
