Name: STPS4045CP
Brand: STMicroelectronics
SKU: STPS4045CP
Availability: InStock

new-10%

STPS4045CP

Manufacturer part number:STPS4045CP

Manufacturer:STMicroelectronics

Description:STPS4045CP datasheet pdf and Diodes - Rectifiers - Arrays product details from STMicroelectronics stock available on our website

Case Package:SOT-23

Datasheet:STPS4045CP Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Radial, Through Hole
Mounting Type	Through Hole
Package / Case	TO-218-3
Diode Element Material	SILICON
Packaging	Tube
JESD-609 Code	e3
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	3
ECCN Code	EAR99
Terminal Finish	Matte Tin (Sn)
Additional Feature	FREE WHEELING DIODE
HTS Code	8541.10.00.80
Subcategory	Rectifier Diodes
Voltage - Rated DC	45V
Terminal Position	SINGLE
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Reach Compliance Code	not_compliant
Current Rating	40A
[email protected] Reflow Temperature-Max (s)	NOT SPECIFIED
Base Part Number	STPS404
Pin Count	3
JESD-30 Code	R-PSFM-T3
Qualification Status	Not Qualified
Operating Temperature (Max)	150°C
Number of Elements	2
Element Configuration	Common Cathode
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Diode Type	Schottky
Current - Reverse Leakage @ Vr	200μA @ 45V
Voltage - Forward (Vf) (Max) @ If	760mV @ 20A
Max Reverse Leakage Current	200μA
Operating Temperature - Junction	175°C Max
Max Surge Current	220A
Application	POWER
Max Reverse Voltage (DC)	45V
Average Rectified Current	20A
Number of Phases	1
JEDEC-95 Code	TO-218AC
Diode Configuration	1 Pair Common Cathode
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

STPS4045CP Product Details

STPS4045CP Overview

Array should be a rule to monArrayor the surge current and not allow Array to exceed 220A.There can be a current drawn from this part of 40A.The maximum reverse leakage current from a semiconductor device when reverse biased is 200μA.
