Name: 1986723-2
Brand: TE Connectivity AMP Connectors
SKU: 1986723-2
Price: 6.70000 USD
Availability: InStock

new

1986723-2

Manufacturer part number:1986723-2

Manufacturer:TE Connectivity AMP Connectors

Description:1986723-2 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from TE Connectivity AMP Connectors stock available on our website

Case Package:SOT-23

Datasheet:1986723-2 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	22 Weeks
Lifecycle Status	ACTIVE (Last Updated: 1 day ago)
Contact Material	Copper Alloy
Mount	Free Hanging, Panel
Mounting Type	Free Hanging (In-Line)
Housing Material	Polyamide (PA), Nylon
Operating Temperature	-40°C~110°C
Packaging	Bulk
Published	2012
Feature	Mating Flange
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Screwless
ECCN Code	EAR99
Connector Type	Plug
Type	Plug, Female Sockets
Color	Green
Voltage - Rated	300V
HTS Code	8536.69.40.40
Pitch	0.138 3.50mm
Orientation	Straight
Insulation Height	0.459 11.66mm
Current Rating	11A
Termination Style	Screwless - Leg Spring, Push-In Spring
Number of Contacts	2
Voltage	300V
ELV	Compliant
Max Current Rating	9A
Number of Levels	1
Current	9A
Wire Gauge (Max)	30 AWG
Wire Gauge (Min)	14 AWG
Wire/Cable Gauge	30 AWG
Contact Mating Finish	Tin
Wire Gauge or Range - AWG	14-30 AWG
Plug Wire Entry	180°
Wire Gauge or Range - mm²	0.05-2mm2
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
REACH SVHC	Unknown
RoHS Status	RoHS Compliant

1986723-2 Product Details

1986723-2 Overview

The packaging contains Plug.This device is mounted in the Free Hanging (In-Line) position.It's packaged in a Bulk case.Several benefits come from the Mating Flange feature.Free Hanging, Panel represents the mounting point for the part.It runs at -40°C~110°C Operating Temperature.There are a lot of similarities between this part and other Plug, Female Sockets products.
