Name: 284041-5
Brand: TE Connectivity AMP Connectors
SKU: 284041-5
Price: 6.49000 USD
Availability: InStock

new-10%

284041-5

Manufacturer part number:284041-5

Manufacturer:TE Connectivity AMP Connectors

Description:284041-5 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from TE Connectivity AMP Connectors stock available on our website

Case Package:SOT-23

Datasheet:284041-5 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	19 Weeks
Lifecycle Status	ACTIVE (Last Updated: 2 days ago)
Contact Material	Phosphor Bronze
Mount	Cable, Free Hanging, PCB
Mounting Type	Free Hanging (In-Line)
Material	Nylon
Housing Material	Polyamide (PA66), Nylon 6/6
Operating Temperature	-40°C~110°C
Packaging	Bulk
Published	2002
Series	Buchanan
Feature	Retention Latches (Non-Wire Side)
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Screw
ECCN Code	EAR99
Connector Type	Plug
Type	Plug, Female Sockets
Color	Green
Number of Rows	1
Gender	Male
Voltage - Rated	300V
Additional Feature	94V-0, PA66
Pitch	0.200 5.08mm
Orientation	Straight
Depth	12.5mm
Insulation Height	0.984 25.00mm
Current Rating	15A
Termination Style	Screw - Rising Cage Clamp
Number of Contacts	5
Voltage	300V
ELV	Compliant
Max Voltage Rating (AC)	300V
Max Current Rating	15A
Number of Levels	1
Current	15A
Wire Gauge (Max)	30 AWG
Wire Gauge (Min)	12 AWG
Contact Mating Finish	Tin
Number of Decks	1
Wire Gauge or Range - AWG	12-30 AWG
Torque - Screw	0.79 Nm (7.0 Lb-In)
Number of Ways	15
Safety Approval	UL
Plug Wire Entry	270°
Wire Gauge or Range - mm²	0.05-3mm2
Wire Strip Length	6-7.5mm
Screw Size	M3
Max Supply Voltage (AC)	300V
Length	25.4mm
Width	12.5mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

284041-5 Product Details

284041-5 Overview

This product is packaged in a Plug carton.Mounting type Free Hanging (In-Line) is selected for the device.Packaging for the product is carried out via a Bulk case.Buchanan Series product.Additionally, there are other features such as 94V-0, PA66.A number of benefits can be derived from the Retention Latches (Non-Wire Side) feature of this application.There's a Cable, Free Hanging, PCB on the part.Running in -40°C~110°C Operating Temperature.In addition to its benefits, this part also shares many with the other products in the Plug, Female Sockets series.
