Name: 284065-2
Brand: TE Connectivity AMP Connectors
SKU: 284065-2
Price: 2.03000 USD
Availability: InStock

new-10%

284065-2

Manufacturer part number:284065-2

Manufacturer:TE Connectivity AMP Connectors

Description:284065-2 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from TE Connectivity AMP Connectors stock available on our website

Case Package:SOT-23

Datasheet:284065-2 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Lifecycle Status	ACTIVE (Last Updated: 4 months ago)
Contact Material	Copper Alloy
Contact Plating	Tin
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	Polyamide (PA66), Nylon 6/6
Operating Temperature	-40°C~110°C
Packaging	Bulk
Published	2007
Series	Buchanan
Feature	Interlocking (Side)
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Header
Type	Header, Male Pins, Shrouded (4 Side)
Number of Positions	4
Color	Green
Number of Rows	2
Voltage - Rated	300V
Pitch	0.200 5.08mm
Orientation	Straight
Depth	22.9mm
Insulation Height	0.869 22.08mm
Current Rating	15A
Termination Style	Solder
Voltage - Rated AC	300V
Shrouding	Yes
Number of Contacts	4
Housing Color	Green
Voltage	300V
Contact Tail Length	0.138 3.50mm
ELV	Compliant
Max Voltage Rating (AC)	300V
Max Current Rating	15A
Number of Levels	2
Current	12A
Contact Mating Finish	Tin
Voltage - UL	300V
Current - UL	12A
Positions Per Level	2
Header Orientation	Vertical
Number of Positions Per Level	2
Length	14.74mm
Length - Tail	3.5mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

284065-2 Product Details

284065-2 Overview

It comes in a Header package.Through Hole is the mounting type.To package the product, a Bulk case is used.This product is in the Buchanan Series.Its Interlocking (Side) feature makes it more powerful in a number of ways.There is a Through Hole mount on the part.In this case, the device runs at -40°C~110°C Operating Temperature.This part shares lots of benefits with other Header, Male Pins, Shrouded (4 Side) products.
