Name: 284506-5
Brand: TE Connectivity AMP Connectors
SKU: 284506-5
Price: 4.12000 USD
Availability: InStock

new-10%

284506-5

Manufacturer part number:284506-5

Manufacturer:TE Connectivity AMP Connectors

Description:284506-5 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from TE Connectivity AMP Connectors stock available on our website

Case Package:SOT-23

Datasheet:284506-5 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	15 Weeks
Lifecycle Status	ACTIVE (Last Updated: 5 days ago)
Contact Material	Phosphor Bronze
Contact Plating	Tin
Mount	Through Hole
Mounting Type	Free Hanging (In-Line)
Housing Material	Polyamide (PA66), Nylon 6/6
Operating Temperature	-40°C~110°C
Packaging	Bulk
Published	2007
Series	Buchanan
Feature	Side Stacking
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Plug
Type	Plug, Female Sockets
Number of Positions	5
Max Operating Temperature	105°C
Min Operating Temperature	-40°C
Color	Green
Number of Rows	1
Voltage - Rated	300V
Pitch	0.138 3.50mm
Orientation	Right Angle
Depth	15.5mm
Insulation Height	0.437 11.10mm
Current Rating	11A
Termination Style	Screw - Rising Cage Clamp
Voltage - Rated AC	300V
Number of Contacts	5
Housing Color	Green
Voltage	300V
ELV	Compliant
Number of Circuits	5
Max Voltage Rating (AC)	300V
Max Current Rating	11A
Number of Levels	1
Current	11A
Wire Gauge (Max)	30 AWG
Wire Gauge (Min)	30 AWG
Contact Mating Finish	Tin
Voltage - UL	300V
Wire Gauge or Range - AWG	14-30 AWG
Current - UL	11A
Torque - Screw	0.31 Nm (2.7 Lb-In)
Positions Per Level	5
Plug Wire Entry	180°
Thread Size	M2
Wire Gauge or Range - mm²	0.05-2mm2
Wire Strip Length	5-6mm
Number of Positions Per Level	5
Screw Size	M2
Max Supply Voltage (AC)	300V
Length	17.5mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

284506-5 Product Details

284506-5 Overview

Packaging is Plug.The mounting type of the device is Free Hanging (In-Line).An Bulk case is utilized for packaging the product.The product is part of the Buchanan Series.If it is to be used, it should be kept at a temperature below 105°C.There must be a minimum temperature of -40°C for this device to operate.In many ways, it is more powerful due to its Side Stacking feature.Mounting of the part is based on Through Hole.Circuits number 5.It operates at an operating temperature of -40°C~110°C.The benefts of this part are similar to those of other Plug, Female Sockets products.
