Name: 5103308-7
Brand: TE Connectivity AMP Connectors
SKU: 5103308-7
Price: 4.24000 USD
Availability: InStock

new-10%

5103308-7

Manufacturer part number:5103308-7

Manufacturer:TE Connectivity AMP Connectors

Description:5103308-7 datasheet pdf and Rectangular Connectors - Headers, Male Pins product details from TE Connectivity AMP Connectors stock available on our website

Case Package:SOT-23

Datasheet:5103308-7 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	5 Weeks
Lifecycle Status	ACTIVE (Last Updated: 4 days ago)
Contact Material	Brass
Contact Plating	Gold, Tin
Mount	Through Hole
Mounting Type	Through Hole
Contact Shape	Square
Housing Material	Thermoplastic
Operating Temperature	-65°C~105°C
Packaging	Tray
Published	1999
Series	AMP-Latch
JESD-609 Code	e3
Feature	Keying Slot
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Header
Number of Positions	34
Number of Rows	2
Additional Feature	LOW PROFILE, POLARIZED
Fastening Type	Push-Pull
Contact Finish - Mating	Gold or Gold-Palladium
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Male Pin
Mixed Contacts	NO
Option	GENERAL PURPOSE
Current Rating (Amps)	1A per Contact
Orientation	Vertical
Depth	9.14mm
Insulation Height	0.388 9.86mm
Style	Board to Cable/Wire
Number of Positions Loaded	All
Current Rating	1A
Pitch - Mating	0.100 2.54mm
Insulation Color	Black
Number of Conductors	ONE
Reference Standard	UL, CSA
Reliability	COMMERCIAL
Row Spacing - Mating	0.100 (2.54mm)
Contact Length - Post	0.120 3.05mm
Shrouding	Shrouded - 4 Wall
Number Of PCB Rows	2
Lead Pitch	2.54mm
Contact Finish - Post	Tin
Contact Length - Mating	0.240 6.10mm
PCB Contact Pattern	RECTANGULAR
Body Breadth	0.36 inch
Contact Gender	Male
UL Flammability Code	94V-0
Lead Length	3.048mm
Operating Supply Voltage	250V
Insulation Resistance	5GOhm
Mating Contact Pitch	0.1 inch
Max Voltage Rating (AC)	250V
Polarization Key	CTR W/GUIDE SLOTS
Dielectric Withstanding Voltage	1000VAC V
Contact Current Rating	1A
Circuit Application	Signal
Mating Connector Lock	Without
Shrouded End Dimension	3.81 mm
Height	8.813mm
Length	50.8mm
Contact Finish Thickness - Mating	15.0μin 0.38μm
Contact Finish Thickness - Post	100.0μin 2.54μm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
REACH SVHC	Unknown
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

5103308-7 Product Details

5103308-7 Overview

It comes in a Header package.Mounting type is Through Hole.It has been determined that a Tray case is necessary to package the product.Product number AMP-Latch belongs to the AMP-Latch Series.Further, there are features such as LOW PROFILE, POLARIZED, to name only a few.A number of features make it more powerful because of its Keying Slot feature.The part is mounted by Through Hole.According to the datasheet, this memory operates at an operating voltage of 250V.The device runs in -65°C~105°C Operating Temperature.
